Fortpro Power Steering Pump Compatible with Cummins N14 Engines, International Heavy Duty Trucks | F255711

Key Features
  • Most of the power steering pump's housing look identical with the pressure port pointing to the same direction, this is why, you should be aware of the direction of rotation because if you don not choose the right one, the pump will not work
  • Direction of Rotation: Right ; Fuel feed hole: 1 1/16-12UN ; Fuel Discharge Hole: 3/4-16UNF
  • Nominal Displacement: 25 ml/r ; Maximum Pressure: 165 bar ; Controlled Flow Rate 25 L/min
  • Highest Rotational speed 500 - 3600 r/min
  • Perfect Fit is a must for Steering Pumps, Ours are precisely built to ensure proper Fit and Performance . Be sure of your truck OEM part number
Specifications
  • Product Line: Steering Components
  • Category Name: Power Steering Pump
  • Part Type: Steering Pump
  • Alternate Part Name: Hydraulic Power Steering Pump
  • Model: PS
  • OEM Part Number: 2108653
  • Application Type: Semi-Trucks, Heavy Duty Trucks
  • Inlet Port Thread Size: 1-1/16-12 UN-2B
  • Mounting Type: 2 Bolt Flange SAE-A SIZE
  • Outlet Port Thread Size: 3/14-16 UNF-2B
  • Material: Cast Iron
  • Max Operating Speed: 3600 rpm
  • Max Relief Pressure: 165 bar
  • Nominal Flow Rate: 25.0 L/min
  • Pump Displacement: 25.0 cm³/rev
  • Shaft Rotation Direction: Left-Hand
  • Shaft Type: 11-Tooth Spline
  • Net Weight: 8.20 lb.

Intended Application
Compatible with Cummins N14, International Navistar Engines.

Cross-references
  • 2108653, 3538860C91, 465TRW10, 542-0267-10, 542026710, PS282815L103
×
×
×
×
×
×
×
×
