Murr Elektronik 857725 MCS Power Supply Units 2-PHASE

Product Description

INPUT: 340...460 V AC

OUTPUT: 24...28 V DC

Current: 5 A

Electrical data
Parallel connection Yes
Number of devices parallel connection max. 5
Series connection Yes
Number of devices series connection max. 2
Electrical data | Supply
Protective measure SELV
Power frequency 50 ... 60 Hz
Electrical data | Input
Input voltage AC 400 V
Input voltage AC min. 340 V
Input voltage AC max. 470 V
Current input AC 0,85 A
Inrush current max. 22 A
Efficiency 88 % @ 400 V AC
External back-up fuse per phase max. 10 A
Electrical data | Output
Output voltage adjustable Yes
Output voltage DC 24 V
Output voltage DC min. 24 V
Output voltage DC max. 28 V
Output current 5 A
Output current (UL) 6 A
Selectable switch-off mode front sided plug link (automatic re-start or definite shut-off)
Mains failure bridging min. 10 ms @ 400 V AC
Spikes (s-s) max. 100 mV
Ripple effective max. 20 mV
Device protection | Electrical
Overload protection output Yes
Short-circuit protection output Yes
Mechanical data | Mounting data
Height 127 mm
Width 68 mm
Depth 140 mm
Mounting method geschnappt
Suitable for mounting type Mounting rail TH35, (EN 60715)
Environmental characteristics | Electromagnetic compatibility
Interference emission IEC/EN 55022
Environmental characteristics | Climatic
Operating temperature min. 0 °C
Operating temperature max. 60 °C
Ambient temperature (storage, transport) -25 °C … 85 °C
Relative humidity (operation) 5 % … 95 %
Additional condition relative humidity no condensation
Conformity
Product standard EN IEC 61010-2-201, EN 61204-3

Connection type 1
Family construction form terminal
No. of poles 3
Gender female
Color contact carrier green
Connection Spring clamp terminals FK
PIN 1 PE
PIN 2 L 2
PIN 3 L 1
Connection type 2
Family construction form terminal
No. of poles 4
Gender female
Color contact carrier green
Connection Spring clamp terminals FK
PIN 1 -
PIN 2 -
PIN 3 +
PIN 4 +

URL Webshop https://shop.murrelektronik.com/857725
GTIN 4048879076401
EU-Customs tariff number 85044083
US-Customs tariff number 8504409550
ECLASS-6.0 27049002
ECLASS-6.1 27049002
ECLASS-7.0 27049002
ECLASS-7.1 27049002
ECLASS-8.0 27049002
ECLASS-8.1 27049002
ECLASS-9.0 27040701
ECLASS-9.1 27040701
ECLASS-10.0.1 27040701
ECLASS-10.1 27040701
ECLASS-11.0 27040701
ECLASS-11.1 27040701
ECLASS-12.0 27040701
ECLASS-13.0 27040701
ECLASS-14.0 27040701
ETIM-5.0 EC002542
ETIM-6.0 EC002542
ETIM-7.0 EC002542
ETIM-8.0 EC002542
ETIM-9.0 EC002542
ETIM-10.0 EC002542
customs tariff number 85044083
EAN 4048879076401
Packaging unit 1
