✅ PRODUCT OVERVIEW
Compact automated dispensing or pick‑and‑place module with resin shrapnel (spring plate) mechanism for precise vertical movement.
Designed for light‑duty automation (1‑2 kg load) with a short‑range communication distance of 150‑260 mm.
Low‑power operation (15W) at 220V, suitable for integration into small assembly, dispensing, or sorting systems.
📋 TECHNICAL SPECIFICATIONS
Model: KH‑100#
Shrapnel (Spring Plate) Material: Resin
Voltage: 220V
Power: 15W
Communication / Stroke Distance: 150 – 260 mm
Load‑Bearing Capacity: 1 – 2 kg
🚀 KEY FEATURES & APPLICATIONS
Precision Movement: Resin spring plate provides smooth, controlled vertical actuation.
Compact & Efficient: Low power consumption (15W) ideal for continuous operation in compact machines.
Short‑Range Automation: Optimized for small‑scale pick‑and‑place, glue dispensing, part insertion, or sorting tasks.
Easy Integration: Standard module design for straightforward mounting into custom automation setups.
📦 TYPICAL APPLICATIONS
Small‑component assembly lines
Micro‑dispensing systems (adhesives, lubricants)
Light part sorting & transfer
Laboratory automation & prototyping
Electronic manufacturing processes
⚠️ OPERATIONAL NOTES
Ensure 220V power supply compatibility.
Operate within specified load (1‑2 kg) and stroke (150‑260 mm) limits.
The resin spring mechanism may require periodic inspection for wear or fatigue.
Ideal for clean, low‑impact environments; not suitable for heavy‑duty or high‑shock applications.
📦 PACKAGE INCLUDES
1 x KH‑100# Automation Module
(Mounting brackets, controllers, and tubing/wiring may be sold separately. Confirm with seller.)
