1 PCS Murrelektronik 85002 Evolution Power Supply 3-Phase

Product Description

Description

INPUT: 3× 360...520 V AC / 480...745 V DC
OUTPUT: 22...28 V DC
Current: 20 A
CE
cULus
DNV
EAC
UKCA

Electrical data
Parallel connection Yes
Number of devices parallel connection max. 5
Series connection Yes
Number of devices series connection max. 2
Electrical data | Supply
Protective measure SELV
Power frequency 50 ... 60 Hz
Electrical data | Input
Phase number input 3
Input voltage AC min. 324 V
Input voltage AC max. 572 V
Nominal input voltage AC 3
Input voltage DC min. 480 V
Input voltage DC max. 745 V
Input current AC (3-phase) 1,3 A
Nominal current AC 3
Inrush current max. 19 A
Efficiency 90 % @ 3× 400 V AC 89 % @ 3× 520 V AC
External back-up fuse per phase max. 20 A
Electrical data | Output
Output voltage adjustable Yes
Output voltage DC 24 V
Output voltage DC min. 22 V
Output voltage DC max. 28 V
Output current 20 A
Mains failure bridging min. 19 ms @ 400 V AC
Power Boost 150 %
Duration Power Boost min. 4 s
Spikes (s-s) max. 100 mV
Ripple effective max. 50 mV
Device protection | Electrical
Degree of protection (EN IEC 60529) IP20
Overload protection output Yes
Short-circuit protection output Yes
Mechanical data | Mounting data
Height 132 mm
Width 113 mm
Depth 136 mm
Mounting method geschnappt
Suitable for mounting type Mounting rail TH35, (EN 60715)
Environmental characteristics | Electromagnetic compatibility
Interference emission EN IEC 55011, IEC 61000-3-2
Environmental characteristics | Climatic
Operating temperature min. -25 °C
Operating temperature max. 70 °C
Derating 55 °C
Ambient temperature (storage, transport) -40 °C … 85 °C
Relative humidity (operation) 5 % … 95 %
Additional condition relative humidity no condensation
Conformity
Product standard EN IEC 61010-2-201, EN 61204-3
Approvals
SEMI F47 compliant

Connection type 1
Family construction form terminal
No. of poles 4
Gender female
Color contact carrier green
Connection Screw terminals SK
PIN 1 PE
PIN 2 L 1
PIN 3 L 2
PIN 4 L 3
Connection type 2
Family construction form terminal
No. of poles 4
Gender female
Color contact carrier green
Connection Screw terminals SK
PIN 1 +
PIN 2 +
PIN 3 -
PIN 4 -

URL Webshop https://shop.murrelektronik.com/85002
GTIN 4048879000093
EU-Customs tariff number 85044095
US-Customs tariff number 8504409580
ECLASS-6.0 27049002
ECLASS-6.1 27049002
ECLASS-7.0 27049002
ECLASS-7.1 27049002
ECLASS-8.0 27049002
ECLASS-8.1 27049002
ECLASS-9.0 27040701
ECLASS-9.1 27040701
ECLASS-10.0.1 27040701
ECLASS-10.1 27040701
ECLASS-11.0 27040701
ECLASS-11.1 27040701
ECLASS-12.0 27040701
ECLASS-13.0 27040701
ECLASS-14.0 27040701
ETIM-5.0 EC002540
ETIM-6.0 EC002540
ETIM-7.0 EC002540
ETIM-8.0 EC002540
ETIM-9.0 EC002540
ETIM-10.0 EC002540
customs tariff number 85044095
EAN 4048879000093
Packaging unit 1
