2000W Pure Sine Wave Inverter 12V DC to 240V AC

About This Item:

Power your compatible electrical devices wherever mains electricity is unavailable. This 2000W pure sine wave inverter converts 12V DC battery power into 240V AC, making it suitable for caravans, campervans, boats, off-grid applications and mobile workspaces.

Featuring an LCD display, remote control, UK AC socket, USB-A and USB-C ports, this inverter offers convenient power access, clear operating information and multiple protection functions.



Features:

1. 2000W Continuous Power

Delivers 2000W rated continuous output with peak power of at least 4000W, providing power for compatible household appliances, electronics and tools.

Always check the running wattage and start-up power requirements of your appliances before use.

2. Pure Sine Wave Output

Produces a smooth pure sine wave AC output for compatible electrical equipment. Suitable for a range of resistive, inductive and electronic loads when their power requirements are within the inverter's limits.

3. 12V DC to 240V AC Conversion

Converts power from a compatible 12V battery system into 240V AC for suitable UK-plug appliances. Ideal for mobile and off-grid applications where conventional mains power is unavailable.

Please note: This is a 12V DC input model, not a 24V model.

4. LCD Display for Real-Time Monitoring

The LCD display allows you to monitor key operating information, including battery input voltage, battery level, AC output voltage, output current, internal temperature, output frequency and load power, where supported by the model supplied.

5. Remote Control Included

The included remote controller allows convenient switching of the inverter on and off without needing to access the main unit directly.

The remote connects through the RJ45 interface and features operating status indicators. According to the user manual, compatible Cat5e or Cat6 extension cables can be used, with a maximum permitted cable length of 8 metres.

6. USB-A, USB-C and UK AC Socket

Features a UK AC socket, USB-A port and USB-C port for powering compatible equipment and charging supported devices.

Check the connected device's power requirements before use. USB output ratings depend on the specific port specifications.

7. Multiple Protection Functions

The inverter's protection system is designed to help protect the unit and connected equipment against common electrical faults, including:

• Under-voltage and over-voltage

• Overload

• Over-temperature

• Short circuit

• Reverse battery polarity

LED indicators and audible alarms help alert users to operating faults.

8. Intelligent Cooling System

The built-in forced-air cooling system helps manage operating temperature. Intelligent fan control adjusts fan operation according to load conditions to support stable operation.

9. Compact and Practical Design

With dimensions of approximately 345 × 212 × 85mm (13.6 × 8.3 × 3.3in) and a net weight of approximately 3.5kg (7.7lbs), the inverter is designed for practical installation where space matters.



Applications

Household Appliances: Compatible TVs, audio systems, fans, lighting, refrigerators, freezers, coffee machines and other appliances within the inverter's power limits.

Power Tools: Compatible drills, grinders, water pumps, saws and other tools, provided their running and start-up power requirements are suitable.

Office Equipment: Computers, monitors, printers, scanners and other compatible equipment.

Mobile and Outdoor Use: Caravans, campervans, boats, mobile workspaces and suitable off-grid power systems.

Important: Not every appliance listed above is suitable for every inverter or battery setup. High-start-up-current appliances and high-power heating devices require particular attention to their running and peak power requirements.



Technical Specifications

• Rated Continuous Power: 2000W

• Peak Power: ≥4000W

• Input Voltage: 12V DC

• Output Voltage: 240V AC

• Output Waveform: Pure Sine Wave

• Display: LCD

• AC Outlet: UK socket

• USB Ports: USB-A and USB-C

• Remote Control: Included

• Remote Connection: RJ45

• Remote Extension Cable: Compatible Cat5e/Cat6, up to 8m as stated in the manual

• Dimensions: 345 × 212 × 85mm / 13.6 × 8.3 × 3.3in

• Net Weight: Approx. 3.5kg / 7.7lbs

•

Package Includes

• 1 × 2000W Pure Sine Wave Inverter

• 1 × Remote Controller with Connecting Cable

• 1 × User Manual

Not included unless explicitly stated: Battery, battery connection cables, grounding wire, installation wrench and other accessories.

Installation and Safety Information

• Designed for use with a compatible 12V DC battery system only.

• Installation and commissioning should be carried out by a person with appropriate electrical experience.

• Switch off the inverter before connecting it to the battery.

• Observe the correct positive and negative polarity, and connect the grounding wire as instructed in the manual.

• Use appropriately rated battery cables, connectors and protective fuses. Do not replace the cables with undersized alternatives.

• Install in a cool, dry and well-ventilated location, leaving approximately 20–30cm clearance around the unit and keeping ventilation openings unobstructed.

• The operating temperature range stated in the manual is -20°C to 50°C. Avoid humid, dusty or condensation-prone environments.

• Keep away from water, flammable materials and excessive heat.

• Do not exceed the inverter's rated output or the connected appliance's start-up requirements.

• Never connect the inverter's AC output directly to a household mains outlet.

Please check your appliance requirements, battery capacity and installation conditions before purchasing.
