Murrelektronik 6652519 MIRO 6.2 OPTO-COUPLER MODULE IN: 53 VDC OUT: 48 VDC / 6 A

Product Description

Description

Transistor 6 A
24 V DC
Spring clamp terminals
CE
cCSAus
cURus
UKCA

Electrical data | Input
Input voltage DC min. 10 V
Input voltage DC max. 53 V
Input voltage OFF DC min. 0 V
Input voltage OFF DC max. 5 V
Current input DC 10 mA
Electrical data | Output
Voltage drop DC max. 0,1 V
Quiescent current OFF max. 0,025 mA
Switch on delay max. 2 ms
Switch off delay max. 5 ms
Voltage switching DC min. 5 V
Switching voltage DC max. 48 V
Switching current 1 mA
Switching current 6 A
Switching frequency ohmic 1 Hz
Switching frequency inductive max. 0,1 Hz
Diagnostics
Status indication LED yellow
Device protection | Electrical
Rated insulation voltage 2.750 V
Device protection | Media
Flame resistance flame retardant
Mechanical data | Material data
housing Plastic
Color housing black
Mechanical data | Mounting data
Height 78 mm
Width 6,2 mm
Depth 70 mm
Mounting method geschnappt
Suitable for mounting type (EN 60715), mounting rail
Environmental characteristics | Climatic
Operating temperature min. -20 °C
Operating temperature max. 60 °C

Connection type 1
Family construction form terminal
No. of poles 1
Gender female
Color contact carrier black
Connection Spring clamp terminals FK
PIN 1 13 +
Connection type 2
Family construction form terminal
No. of poles 1
Gender female
Color contact carrier black
Connection Spring clamp terminals FK
PIN 1 14
Connection type 3
Family construction form terminal
No. of poles 1
Gender female
Color contact carrier black
Connection Spring clamp terminals FK
PIN 1 + A 1
Connection type 4
Family construction form terminal
No. of poles 1
Gender female
Color contact carrier black
Connection Spring clamp terminals FK
PIN 1 - A 2

URL Webshop https://shop.murrelektronik.com/6652519
GTIN 4048879021753
EU-Customs tariff number 85414900
US-Customs tariff number 8541499500
ECLASS-6.0 27371601
ECLASS-6.1 27371604
ECLASS-7.0 27371604
ECLASS-7.1 27371604
ECLASS-8.0 27371604
ECLASS-8.1 27371604
ECLASS-9.0 27371604
ECLASS-9.1 27371604
ECLASS-10.0.1 27371604
ECLASS-10.1 27371604
ECLASS-11.0 27371604
ECLASS-11.1 27371604
ECLASS-12.0 27371604
ECLASS-13.0 27371604
ECLASS-14.0 27371604
ETIM-5.0 EC001504
ETIM-6.0 EC001504
ETIM-7.0 EC001504
ETIM-8.0 EC001504
ETIM-9.0 EC001504
ETIM-10.0 EC001504
customs tariff number 85414900
EAN 4048879021753
Packaging unit 1
