Murrelektronik 8000-88510-3981000 EXACT12, 8XM12, 5-POLE, MOULDED CABLE
Description
8-way, 5-pole
Further cable lengths on request.
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Further cable lengths on request.
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Technical Data
Electrical data | Supply
| Operating voltage DC | 24 V |
|---|---|
| Current operating per contact max. | 4 A |
Installation | Connection
| Mounting set | M12 x 1 |
|---|
Device protection | Electrical
| Degree of protection (EN IEC 60529) | IP67, IP65 |
|---|
Device protection | Media
| Flame resistance | flame retardant |
|---|
Mechanical data | Material data
| housing | Plastic |
|---|
Mechanical data | Mounting data
| Mounting method | Schraubgewinde |
|---|---|
| Cable length | 10 m |
Environmental characteristics | Climatic
| Operating temperature min. | -20 °C |
|---|---|
| Operating temperature max. | 70 °C |
| Additional condition temperature range | depending on cable quality |
Cable data
General data | Cable
| Cable identification | 398 |
|---|---|
| Cable Type | 2 |
| Function cable | Hybrid, Signal, Power |
| Cable weigth | 150 g/m |
| UL AWM Style | 20549 / 1731 |
Structure | Cable
| Stranding | 1 × 7 wires around core filler twisted |
|---|---|
| Stranding (type 2) | 1 × 12 wires stranded around stranding combination |
| Filler | Yes |
| Wire arrangement | (WH, GYPK, BNGN, YE, GNWH, GN, RDBU), BNGY, BK, GYWH, RD, BNYE, PK, YEWH, GY, BU, BN, GNYE, VT |
Wire data | Cable
| Material wire insulation | PVC |
|---|---|
| Amount wires | 16 |
| Outer diameter insulation | 1.3 mm ± 0.1 mm |
| Conductor crosssection (wire) | 0,34 mm² |
| Material conductor wire | Stranded copper wire, bare |
| Core construction (wire) | 19 × 0.15 mm |
| Material properties wire insulation | good machinability |
| Ingredient freeness wire insulation | lead-free, cadmium-free, CFC-free, silicone-free |
| Electrical function wire (type 2) | Power |
| Material wire insulation (type 2) | PVC |
| Amount wires (type 2) | 3 |
| Outer diameter wire insulation (type 2) | 1.8 mm ± 0.1 mm |
| Conductor crosssection (wire type 2) | 0,75 mm² |
| Material conductor wire (type 2) | Stranded copper wire, bare |
| Core construction (wire type 2) | 42 × 0.15 mm |
| Material properties wire insulation (type 2) | good machinability |
| Ingredient freeness wire insulation (type 2) | lead-free, cadmium-free, CFC-free, silicone-free |
Jacket data | Cable
| Material jacket | PUR |
|---|---|
| Outer-diameter (jacket) | 10 mm ± 5 % |
| Jacket Color | gray / RAL 7040 |
| Material inner jacket | PVC |
| Color (inner jacket) | gray |
| Freedom from ingredients (jacket) | lead-free, cadmium-free, CFC-free, silicone-free |
| Material property (jacket) | abrasion-resistant, low adhesion, good machinability, matte |
Electrical data | Cable
| Conductor resistance (wire) | 57 Ω/km @ 20 °C |
|---|---|
| Conductor resistance (wire type 2) | 26 Ω/km @ 20 °C |
| Max. rated voltage (conductor - ground) | 300 V |
| Max. rated voltage (conductor - conductor) | 300 V |
| Withstand voltage (wire - wire) | 2 kV @ 60 s |
| Withstand voltage (wire - jacket) | 2 kV @ 60 s |
| Current load capacity max. (wire) | 4 A |
| Current load capacity max. Wire (type 2) | 12 A |
| Current load capacity (standard) | to DIN VDE 0298-4 |
Temperature range | Cable
| Operating temperature (static) | -30 °C … 80 °C |
|---|---|
| Operating temperature (dynamic) | -5 °C … 70 °C |
| Operating temperature (drag chain) | -5 °C … 60 °C |
Resistances | Cable
| Flame resistance | UL 1581 § 1090, CSA FT2, IEC 60332-2-2 |
|---|---|
| Oil resistance | IEC 60811-404 |
| Chemical resistance | good |
| Other resistances | good resistance to gasoline, resistant to hydrolysis, resistant to microbes |
| Notes | application-related testing |
Installation | Cable
| Bending radius (fixed) | 5 × Outer diameter |
|---|---|
| Bending radius (dynamic) | 10 × Outer diameter |
| No. of bending cycles (C-track) | 2 Mio. @ 25 °C |
| Traversing distance (C-track) | 5 m @ 25 °C |
| Travel speed (C-track) | 2 m/s @ 25 °C |
| Acceleration (C-track) | 10 m/s² @ 25 °C |
Connection data
Connection type 1
| Family construction form | free cable end |
|---|---|
| No. of poles | 19 |
Connection type 2
| Family construction form | M12 |
|---|---|
| No. of poles | 5 |
| Coding | A |
| Gender | female |
| Color contact carrier | black |
| PIN 1 | + |
| PIN 2 | NC S 2 |
| PIN 3 | - |
| PIN 4 | NO S 1 |
| PIN 5 | PE |
Commercial data
| URL Webshop | https://shop.murrelektronik.com/8000-88510-3981000 |
|---|---|
| GTIN | 4048879054010 |
| EU-Customs tariff number | 85444290 |
| US-Customs tariff number | 8544429090 |
| ECLASS-6.0 | 27143423 |
| ECLASS-6.1 | 27279219 |
| ECLASS-7.0 | 27279219 |
| ECLASS-7.1 | 27279219 |
| ECLASS-8.0 | 27279219 |
| ECLASS-8.1 | 27279219 |
| ECLASS-9.0 | 27440108 |
| ECLASS-9.1 | 27440108 |
| ECLASS-10.0.1 | 27440108 |
| ECLASS-10.1 | 27440108 |
| ECLASS-11.0 | 27440108 |
| ECLASS-11.1 | 27440108 |
| ECLASS-12.0 | 27440108 |
| ECLASS-13.0 | 27440108 |
| ECLASS-14.0 | 27440108 |
| ETIM-5.0 | EC002585 |
| ETIM-6.0 | EC002585 |
| ETIM-7.0 | EC002585 |
| ETIM-8.0 | EC002585 |
| ETIM-9.0 | EC002585 |
| ETIM-10.0 | EC002585 |
| customs tariff number | 85444290 |
| EAN | 4048879054010 |
| Packaging unit | 1 |
