The ELX200-15 is a 15in 2-way passive full-range loudspeaker engineered to deliver high output and reliable performance. It provides a calculated peak SPL of 130 dB and a peak power rating of 1200 W. The model is built to withstand rigorous use, verified by extensive abuse and endurance testing.

Key design elements include a 1.4 inch DH-1L titanium compression driver with a 1 inch exit and an EVS-15M 15in woofer engineered for durability and low-frequency extension. The EV-patented Signal Synchronized Transducers (SST) waveguide produces consistent coverage and reduced distortion. Professional-grade hardware such as three M10 suspension points and integrated pole-mount are included for flexible deployment.

Acoustic performance is balanced for clarity and headroom with a specified frequency response of 77 Hz - 16 kHz (-3 dB) and an extended range to 52 Hz - 19 kHz (-10 dB). The system crossover is set at 1.6 kHz and axial sensitivity is 95 dB (1 W at 1 m). Nominal impedance is 8 ohms with a minimum impedance listed as 7.0 ohms and continuous power handling of 300 W.

Connectivity is handled via dual NL4 connectors to support standard professional speaker cabling and parallel runs. The enclosure is a polypropylene composite for a lightweight yet robust assembly and the grille is 18 AWG steel with powdercoat. Available color options include Black or White to suit installed environments or mobile rigs.

This speaker is well suited to live sound reinforcement, portable PA systems, and installed audio where high output and dependable operation are required. It provides 90 degree horizontal by 60 degree vertical nominal coverage, making it appropriate for stage monitoring, main PA duties in small to medium venues, and speech reinforcement. The system is designed to integrate simply with common amplifiers and signal processing workflows.

Installation and field use are simplified by the ZLX-style three-handle layout for handling and the integrated pole-mount for quick tripod deployment. The enclosure dimensions and manageable weight support portable setups while the forged eyebolts and M10 points accommodate flown installations. Overall, the ELX200-15 balances efficient transducer design with a rugged enclosure to deliver reliable, loud and clear sound in professional applications.

Specifications:
