Compatibility:

For 2004-2010 Fit For Ford Explorer 4.0L

For 2007-2010 Fit For Ford Explorer Sport Trac 4.0L

For 2004-2006 Fit For Ford F-150 4.6L

For 2006-2010 Fit For Ford Mustang 4.0L

For 2005-2011 Fit For Ford Crown Victoria 4.6L

For 2005-2006 Fit For Ford E-150 4.6L

For 2005-2014 Fit For Ford E-150 5.4L

For 2005 Fit For Ford E-150 Club Wagon 4.6L

For 2005 Fit For Ford E-150 Club Wagon 5.4L

For 2007-2008 Fit For Ford E-150 Econoline 5.4L

For 2005-2014 Fit For Ford E-250 5.4L

For 2005 Fit For Ford E-350 Club Wagon 5.4L

For 2005-2015 Fit For Ford E-350 Super Duty 5.4L

For 2005-2011 Fit For Mercury Grand Marquis 4.6L

For 2004-2010 Fit For Mercury Mountaineer 4.0L

For 2003-2005 Fit For Lincoln LS 3.0L

For 2005-2011 Fit For Lincoln Town Car 4.6L

Reference Number：

67-6000,337-05428, S20020 ,TB1014,6R3Z9E926AA, 9W7Z9E926A, 9W7Z9E926AA, 9W7Z9E926B, AA5Z9E926A

NOTE:

Before installing the new assembly, inspect the intake-manifold-to-throttle-body gasket for damage.  If it is damaged, it must be replaced.

If it is in good condition, it can be reused.

WARNING:

DO NOT place fingers in or around the throttle body plate. If the throttle body is energized, the throttle plate could move causing personal injury. Always disconnect the negative battery cable prior to servicing the throttle body.

CAUTION:

DO NOT move the throttle plate while power is connected to the throttle body. This may cause fault codes to set.

Q: Is there anything that has to be done after installing the replacement throttle body?

A: A relearn calibration procedure is necessary after installation of replacement throttle body

Q: What is throttle body relearn?

A: Idle Relearn (aka throttle body relearn) is the procedure that is required to obtain the correct idle speed after replacing electronic throttle body, disconnecting a battery cable, clearing a check engine light, etc.

Relearn A MECHANICALLY CONTROLLED THROTTLE BODY

1. Remove terminals from the battery for 15 minutes.

2. Start the engine. Let it idle for 10 minutes. Remember not to switch on any additional consumers.

3. Stop the engine for about 10 seconds. Start it again.

4. Wait until the power unit warms up to the operating temperature. After that, you can start using the vehicle.

Take notice: you might need to drive 150–200 km until the idling stabilises.

Relearn AN ELECTRONICALLY CONTROLLED THROTTLE BODY

The readjustment process might vary in different vehicles. Therefore, before you start the procedure, consult the vehicle manual for the exact step sequence.

The general algorithm is as follows:

1. Study procedure and try to remember it. You’ll have to act quickly so you won’t have time to check the details.

2. Start the engine. Warm it up to the working temperature.Stop it for 10 seconds.

3. Switch on the ignition for 3 seconds.

4. Press the accelerator pedal quickly for 5 times. One depression should take one second.

5. Press the gas pedal to the floor for 7 seconds. Keep it depressed until the “Check Engine” light burns steady and hold it for 3 more seconds.

6. Press the gas pedal to the floor for 7 seconds. Keep it depressed until the “Check Engine” light burns steady and hold it for 3 more seconds.

7. Release the gas pedal and start the engine.

Q: HOW TO PREVENT THE THROTTLE BODY FROM GETTING DIRTY?

A: 1. Use only high-quality fuel. Otherwise, impurities and contaminants will get inside the engine causing the rapid formation of carbon deposits on the throttle body. For the same reason, you shouldn’t neglect the fuel filter replacement. It is recommended to flush the fuel tank from time to time.

2. Replace the air filter on time. Always make sure that the intake system is air-tight. This simple check prevents unfiltered air from being sucked into the intake system in places where its components are not connected tightly.

3. Always make sure that the crankcase ventilation system is fault-free. Its malfunctions cause a fast formation of oily deposits on elements of the throttle body.
