Feature:
1. Compact size and easy installation.
2. BNC male to BNC female with mini cable on both sides
3. Passive, no power required.
4. Prevents video-signal distortion caused by video ground loops
5. Eliminates picture tearing , cross talk and rolling.
Specification:
Features:
- Compact size and easy installation.
- BNC male to BNC female with mini cable on both sides.
- Passive, no power required.
- Prevents video-signal distortion caused by video ground loops.
- Eliminates picture tearing , cross talk and rolling
- Built in video BALUN, perfect to work with DVR to immunity DVR interference , for extra interference rejection
- Built in TVS for surge protection.
- No filter ground isolator, suitable for coaxial grounding isolation.
- HD-TVI/CVI/AHD/CVBS 4 in 1 ground loop lsolated videa balun.
- Up to 230m(754ft)for HD-TVI 720p camera
- Up to 250m(820ft)for HD-TVI 1080p camera
- Up to 440m( 1443f) for HD-CVI 720p camera.
- Up to 240m(787f) for HD-CVI 1080p camera.
- Up to 320m( 1053t)for AHD 1080p camera.
- Up to 330m(1082ft) for AHD 1080p camera.
- Wave Filter Design, Anti- Static Design
- protection design Grade: III
- 60 dB crosstalk and noise immunity
- Exceptional interference rejection.
- Video signal strength is stronger than filtered.
Specification:
Item Type: Ground Loop Isolator
Shell Material: Plastic
Color: Black
Package Weight: 38g/1.34oz
Item Size: 50 * 20 * 20mm/1.96 * 0.78 * 0.78inch(Approx.)
Insertion loss 0.5db
Frequency response 0-3db at 10 MHZ
Input Resistance 75ohm
Output Resistance 75ohm
Isolation Voltage 600VDC(Min)
Insulation resistance 100m Ohm
Transient Voltage suppressors 12 Vrms
Cable length: 30cm( approx)
Design: ABS plastic injection-wide, waterproof, compact
Package List:
1 * Ground Loop Isolator
