Specifications:
- Bore diameter (standard): 54.00 mm
- Piston size: 53.94 mm
- Total height: 58.00 mm
- Connecting rod head bushing bore diameter for piston pin: 15.00 mm
- Compression height: 22.00 mm
- Piston ring gap (E): 0.00 mm
- Distance between pin yoke arms: 20.00 mm
- Piston head type: Flat
- Coating: Mos2 Skirt Coating
- Additional information: Cast Piston
- OEM Equivalent Code: 503.30.007.500
- Country of Origin: Taiwan
- GTIN: 00193564280091
- Piston Ring Part No.: 02.6220
- Piston Pin Part #: 04.1545
- Circlip Part #: 05.1510
| Brand | Model | Model Year | Model year to |
|---|---|---|---|
| KTM | 125 SX | 2001 | 2006 |
