1/2" Water Flow Sensor Switch With Temperature Detection For Turbine Liquid Sensor, Hall Flow Meters, Copper Shell

Features:

ROHS standards: The water flow sensor is mainly composed of copper valve body, water flow rotor assembly and Hall sensor. Raw materials meet ROHS standards.

Principle: Installed at the water inlet end of the water heater, it is used to detect the water inflow. When water passes through the water flow rotor assembly, the magnetic rotor rotates and the rotation speed changes with the flow change. The Hall sensor outputs the corresponding pulse signal and feeds it back to the controller, and the controller judges the water inflow and regulates it.

Sealing Property: seal each hole, and add 1.7Mpa water pressure test for 1 minute without leakage and deformation.

Application: water heater, broiler and heat pump, etc.

The package: 1* Water flow sensor(With temperature probe).

Specifications:

Item name: Water flow sensor

Type: Hall flow rate meter

Model: YF-B7

Material: copper

Application: water heater, broiler and heat pump ...etc.

Interface size: G 1/2"

Working voltage range: DC3.5 to 24V

Inner diameter/outer diameter: 13.7mm/20.3mm

Length of screw teeth: 16mm for long teeth and 10.5mm for short teeth.

Water pressure resistance: ≤1.75MPa

Output pulse high level: > DC 4.7V (input voltage DC 5V)

Duty cycle of output pulse: 50%±10%

Insulation resistance: > 100MΩ

Flow range: within 1 to 25L/min, ±3%

Flow pulse: (11*Q) Q=L/Min±3%, that is, 660 pulses a liter of water.

Application: water heater, broiler and heat pump, etc.

Mounting position: horizontal & vertical

Connection mode: Red, IN, connected to the positive electrode/Yellow, OUT, signal output line/Black, GND, connected to negative electrode.

Precautions: 1.Violent impact and chemical erosion are strictly prohibited. 2.It is forbidden to throw or collision. 3.Install in the direction of the installation arrow on the product. 4.The medium temperature should not exceed 120℃.

Note:

Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 10-30mm.
