Mpatible Vehicles:
For Dodge Caliber 2012-2020
For Fiat Freemont 2012-2020
Note:
1.Vehicle Compatibility Chart May Vary Depending On Vehicle Options, Production Dates, And Install Application. Please Inquire Before Purchase.
2.Wire Harness Does Not Work On Vehicles With Premium Factory Sound System.
3. Wiring Harness Is NOT Compatible With Premium BOSE, Amplified Sound Systems And Onstar.
4. Please Verify Your Vehicle's Original Sound System Specifications Before Purchasing Your Harness.
Features:
●HD 9'' 2.5D Tempered Glass Mirror auto radio player
●Wireless Carplay: You can choose wired connection or wireless connection to carplay, connect to Apple mobile phone, access mobile phone address book, mail, notification, map navigation, music, video and other information, and realize voice control.
●Wireless Android auto: The Wireless Android auto car system can closely integrate the user's Android phone and player, and realize navigation, make calls, send and receive information, listen to music and other operations through data cable connection;
●Built-in GPS Navigation: Users can purchase directly from play store for offline navigation. With wifi connected, Google Maps can be used perfectly, you can go anywhere you want and never get lost again.
●High definition 1080P: Full capacitance touch screen for easy operation, well designed user interface for car only
● Built-in WIFI and 4G network: Connect WIFI and 4G network, you will find a new world, the most convenient is online map.
(The car requires a SIM card to access the Internet, and the product does not include a SIM card;
2G+32G without 4G Internet access function, 4g+64G support 4G Internet access function)
●Rear camera(not included): support AHD high-definition 720P camera image input，you can switch between CVBS and AHD simply by choosing in the settings(requires optional)
●Hi-Fi function: High fidelity, reproduced sound highly similar to your original sound
●Steering wheel control: Through it you can control the functions you need by steering wheel, more convenient
●Built-in Bluetooth with A2DP/Hands Free/Phone book:Bluetooth hands-free calls,Bluetooth music player,Auto loading phonebooks
●Driving recorder: You can choose a recorder, and the car has playback, the evidence can be retained(requires optional)
●Double USB adapter input
●Support file manager: Support download, install and delete over thousands of android apps
●Support multilanguage: Support languages, up to 40 national languages
●You can enjoy music from you mobilephone without any cables, and also support USB connetion.
●FM Radio: Online music you can transfer the music to the car stereo by FM to enjoy the original car stereo sound,with 18 preset stations
●Time Setting:You can use the network or GPS to open the date and time automatically, or you can adjust it manually.
●Support external microphone
Specifications:
System:Android 13
Chipset:8227L-DEMO
Screen size:9''
Memory:4GB (RAM)+64GB (ROM)
Screen resolution:1024*600
Radio chip:MT6625
Power output:4*45W
Work temperature:-20℃-75℃
Steering wheel control function:Support
Power amplifier chip:TDA7388
Radio Band:FM/RDS
Video output:Support
Reversing input: AHD/CVBS
External microphone: support
Split screen: support
Maps:Built-in offline maps(requires internet to download data)
WIFI:Support
USB:Double USB interface
Audio format:APE/FLAC/WAV/MP3/WMA etc
Video format:MKV/RMVB/AVI/MP4/MDV etc
Picture format:PNG/JPEG/JPG/GIF/WBMP/BNP etc
Factory setting keyword:3368
Language:Chinese/English/French/Italian/Korean/Japanese/Arabic/Spanish/Portuguese/Russian/Turkish/Vietnamese/Hebrew/Polish/German
Package Included:
1 x Car MP5 Player
1 x GPS Antenna
1 x Rear Camera lnput Cable
1 x RCA Cable
2 x USB Cable
