H-Beam Con Rod Connecting Rods for Volvo B230 740 760 940 240 2.3 engine 5.984"

Description




Application

For Volvo B230 152mm

for Volvo B230 engines

for Volvo 740 1984–1992 B230 engines 2.3
for Volvo 760 1982–1990 B230 engines 2.3
for Volvo 940 1990–1998 B230 engines 2.3
for Volvo 240 1983–1993 B230 engines 2.3



Specification

Type: 4340 EN24 H-Beam Connecting Rod
Quantity: 4 Pieces as showing in picture
Bolts: Including ARP 2000 bolts (Extra cost for upgrading to ARP L19 bolts)
Bolts size: ARP 2000 3/8" bolts
Horse Power:  Support around 600-800HP
Tolerance: Balanced to +/- 1 gram in set
Warranty: 2 years warranty.

 Strength of the fastening (PSI): ARP 2000 bolts are rated at 220,000 psi, and the optional ARP L19 material at 260,000 psi


Dimensions

Center to center length: 152mm/5.984in
Big end diameter: 52mm/2.047in
Small end diameter: 23mm/0.906in
Big end width: 24.8mm/0.976in
Small end width: 24.8mm/0.976in

 Big end bores tolerance: are honed to a +/-.01mm



Features:

- TÜV PRODUCT TEST AND TÜV ISO 9001 CERTIFIED
- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
 - ARP 2000 bolts ,Optional ARP L9 fasteners available as an upgrade
- 100% CNC machined,Precision rod cap alignment dowels
- All big and small ends are finished with SUNNEN honing machine
- 100% X-rayed, sonic tested
- Heat-treating & Shot-peened for remained consistent and strong. Shot-peened finish to remove potential for stress risers
- Each rod is magnetic particle tested to ensure free of flaws
- H-Beam design reduces weight without compromising strength
- Come with the bronzed bushing suitable for the floating piston pin
- Bores finished to +/- .01 mm
- Balanced to within +/- 1 g per rod
- custom available



Note:

Professional installation is highly recommended (No Instruction Included).

Custom Service: If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs:
1. MOQ:12 pieces
2. Logo custom also available
 3.Provide the sample or the full drawing
