ISP-30 Pneumatic Inner Swelling Pipe Beveling Machine Tube Chamfering Machine
-
Model: ISP-30
-
Description:
This machine is a pneumatic pipe bevelling machine. It has the features of simple installation, light weight, easy to take and etc. Put the tightening organization into the pipe and it can locate the center automatically. This machine can chamfer and bevel the pipes which are made of carbon steel, stainless steel and alloy steel. Besides, it can also process the convex flange. Chamfering angle is from 0° to 45°.
-
Feature:
1. Accurate, highly polished and small deviation
2. Cold cutting, so there is no spark when chamfering the pipe.
3. On-site cold Beveling improves safety
4. Easy set-up & Operation
5. Self-Centering
6. Can be positioned in any direction
7. Feed ratchet spanner makes tool feed / back easily
-
Specification: (this list is for ISP-30 model, if you need other models, pls contact us.)
|
Model
|
Working Range (ID-OD)
|
Wall Thickness
|
Rotation Speed
|
Air pressure
|
|
ISP-30
|
Φ18-28mm
|
≤15
|
50r/min
|
0.6~0.8MPa
|
|
ISP-80
|
Φ28-76mm
|
≤15
|
55r/min
|
|
|
|
|
|
|
ISP-159
|
Φ65-159mm
|
≤20
|
35r/min
|
|
ISP-252-1
|
Φ80-240mm
|
≤20
|
16r/min
|
|
ISP-252-2
|
Φ80-240mm
|
≤75
|
16r/min
|
|
ISP-352-1
|
Φ150-330mm
|
≤20
|
14r/min
|
|
ISP-352-2
|
Φ150-330mm
|
≤75
|
14r/min
|
|
ISP-426-1
|
Φ250-426mm
|
≤20
|
12r/min
|
|
ISP-426-2
|
Φ273-426mm
|
≤75
|
12r/min
|
|
ISP-630-1
|
Φ300-600mm
|
≤20
|
10r/min
|
|
ISP-630-2
|
Φ300-600mm
|
≤75
|
10r/min
|
|
ISP-850-1
|
Φ600-820mm
|
≤20
|
9r/min
|
|
ISP-850-2
|
Φ490-820mm
|
≤75
|
9r/min
|
What in Package:
1 x ISP-80 Pneumatic Pipe Beveling Machine

|
|
