Product Details
1. Supports DC 9-24V wide voltage power supply, suitable for complex industrial environments.
2. Equipped with a RISC-V 32-bit processor at 160MHz for stable operation.
3. Supports WiFi serial pass-through with strong RS232 interface compatibility.
4. Multi-protocol support for TCP/UDP/HTTP/MQTT enables flexible and efficient networking.
5. Supports AP/STA/AP+STA modes for easy and reliable installation.
The WT232_M1 is a multifunctional, multi-protocol WiFi serial port pass-through device. It enables rapid and stable integration of traditional serial devices (such as PLCs, sensors, microcontrollers, etc.) into wireless networks (WiFi) and IoT cloud platforms, facilitating remote data transmission and device control.
Specifications:
Operating Voltage: DC 9~24V, 500mA
Main Control Chip: RISC-V 32-bit processor, 160MHz clock speed
Wireless Network: 2.4GHz
Transmission Interface: WiFi/RS232
Default Management IP: 10.10.0.50
Username: admin
Password: 1234567
Default Serial Parameters: Baud Rate 9600, Parity N, Data Bits 8, Stop Bits 1
Power Supply: DC 9-24V, Average 80mA, Peak 200mA
Protocol Support: Fully supports TCP Server/Client, UDP Server/Client, HTTP Client/MQTT multi-protocol.
Flexible Networking: Supports three operating modes: AP (hotspot), STA (router connection), and AP+STA.
Backend Management: Provides an intuitive local web management interface. No dedicated software download required; all parameter configurations can be completed via a browser.
Advanced Features: Supports heartbeat packets, registration packets, OTA remote upgrades, and parameter restoration.
Antenna Type: Standard 2.4GHz 11cm rod antenna
Mounting Options: DIN35 rail or fixed hole installation
Dimensions: 140*150*30mm
Dimensions without ears: 81X54X32 mm
Dimensions with ears: 90X54X32 mm
1X Module
1X Antenna
