20A 12V 600ml High Pressure Electrolytic Cell for Water Machine

Model 20A-12V-600ML Dual Hydrogen
Constant current 20A
Voltage range 12V
Input Structure Positive / Negative
Hydrogen production 600ml/min
Oxygen production 300ml/min
Effective area of battery 80cm2
Current density≥1A/cm
Single cell voltage 1.7V-2.2V
Number of electrodes 4PCS
Membrane electrode Nafion Proton Exchange Membrane (PEM)
Hydrogen production pressure 0-2MPa
Operating pressure ≤2MPa
Inlet water conductivity ≤5 us/cm
Inlet water temperature 10-50℃
Inlet water inlet British 2 points
Hydrogen outlet 2 points imperial
Oxygen outlet British system 2 points
Working temperature 10-60℃
Water volume ≥1200mL/min
Service life ≥ 10000 h (4-5 years)
Water tank volume ≥2200 ml
Appearance size length * width * height = single 88 * 84 * 90mm
