Fast response when count and count meter
High accuracy
Including three operating modes: Counter, Meter count , Timing
Top Quality & High Performance, easy to operate
Hold the value when power off
|
Specifications |
Counter |
Meter Count |
Timing |
|
Display Digit
|
0.56" 5-digits LED |
||
|
measurement accuracy
|
|
0.0001‰ |
|
|
Measure Range |
0-99999 Times |
0-99999 M (1m counted once) |
999.99S |
|
input signal / amplitude |
Dry contact、PNP、NPN、Pulse/3－30V |
||
|
Input Resistance
|
100KΩ |
||
|
Power supply |
12-24VDC |
||
|
Withstand voltage |
AC2000V 1min Between the External terminal and the shell |
||
|
Anti-vibration |
Vibration Frequency ：1－100HZ，Acceleration: 50m/s2 |
||
|
Operating Temperature |
-30℃ - +70℃(-22℉- +158℉) |
||
|
Humidity |
10－90% RH |
||
|
Storage Temperature |
－40℃－＋80℃ (-40℉- +176℉) |
||
|
Panel Dimensions(mm) |
79X43X25（L×W×H) |
||
|
Cut-out Dimensions (mm) |
75X39.5（L×W） |
||
Please use the item in normal environment;
Input signal should meet the requirements of impedance,
if the internal impedance of the input signal is big and you need to change the impedance .
Package Included:
1PCS*DC12-24V 0.56" Red LED Digital Counter Meter Count Timer Timing Three Function
