2pcs MaXpeedingRods Connecting Rods for Fiat 500 Old Model  2 cylinder 4.6457"

Description





Introduction

MaXpeedingRods H-beam connecting rods are designed for demanding racing applications to increase horsepower and efficiency. The strength is suitable for high-horsepower applications while keeping the weight light. Professional processing makes it have super high wear resistance and excellent durability.



Application

Compatible for Fiat 500 Old Model   2 cylinder 118mm
Notice:Other options C/C: 120/124/126/130mm



Specification

*Type: Forged 4340 aircraft chrome moly quality steel for racing
*H-beam Conrods Quantity: 2 Pieces as showing in picture
*Bolts: Including ARP 2000 5/16" bolts  (Note: Extra cost for upgrading to ARP L19 bolts)
*The connecting rods all include ARP 2000 bolts, which are rated at 220,000 psi, and the optional ARP L19 material at 260,000 psi is available as an upgraded product.
*Advertised Horsepower Rating:200HP/piece
*Top acceleration: 9000rpm
*package size:20CM*10CM*7CM





Dimension

Center to center length:118mm/4.646"
Big end diameter: 47.13mm/1.856"
Small end diameter: 20mm/0.787"
Big end width: 24.7mm/0.972"
Small end width: 18.5mm/0.728"



Features

1. TüV Certification Con Rods;
2. Material: Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing;
3. ARP 2000 bolts ,Optional ARP L19 fasteners available as an upgrade;
4. H-Beam design reduces weight without compromising strength;
5.Heat-treating & Shot-peened for remained consistent and strong. Shot-peened finish to remove potential for stress risers;
6.100% CNC machined,Precision rod cap alignment dowels;
7.Bores finished to +/- .01 mm;
8.Balanced to within +/- 1 g per rod;
9. Each rod is magnetic particle tested to ensure free of flaws;
10.100% X-rayed, sonic tested.




Note

*Professional installation is highly recommended.
