Attention
◆This display is UART2 Protocol
◆You must make sure that your controller is a JN controller. Because this JN LCD display is only compatible with the JN controller. They have the same communication protocol.
Parameter:
●Type: LCD GD02 display
●Voltage: 24V,36V,48V,60V
●Colour: Black
●Weight: 136g(All Accessories)
●Grip size: Φ22.2mm
●Display line length: SM connector, about 165cm/WP connector, about 26cm
Function
1. Travel time display (single travel time (TM) and total travel time (TTM) display);
2. Driving speed display (real-time speed (KM/H or MPH), single maximum speed (MXS) and single average speed (AVS) display;
3. Travel distance display (single travel distance (DST) and total travel distance (ODO) display;
4. Turn on the throttle display (THROTTLE);
5. Power-assisted start (PAS) display;
6. Assist ratio (or throttle) gear (ASSIST) switch;
7.6KM/H power assisted push function;
8. Battery capacity indicator;
9. Real-time battery voltage (VOL) display;
10. Brake display;
11. Turn on the backlight and lights;
12. Data cleaning;
13. Fault code display;
14. User parameter setting
15.24V, 36V, 48V, 60V power supply voltage can be automatically identified and compatible.
Packing List
1.LCD GD02 display
2. Display the manual
