AC Compressors:

Compressors are the heart of the A/C system, with a heavy responsibility to pump A/C refrigerant throughout the automobile’s A/C system. We take the upmost care when developing new compressors. We always make sure that our new compressors meet exact specifications, When you purchase a new compressor from Topcn, you are receiving a high quality product at price that is very affordable.



Feature:

• 【PREMIUM ALUMINUM MATERIAL】- This ac air compressor is a replacement compressor and clutch. Its main body is made of high-strength aluminum material, which is durable, rigid, and wearable. It will not crack, break, or leak. Such high-quality ensures a long-time use for each compressor kit.
• 【STRONG COOLING FUNCTION】- The auto ac compressor can provide sufficient pressure, which increases power force and decreases engine load. It dramatically improves the cooling function: features as high and stable efficiency, safety, and reliability.
• 【LOW NOISE & LOW FUEL CONSUMPTION】- AC compressor works excellent and has low noise with a better experience. With a lower load factor, low power will be input when driving at high speed, which increases fuel economy and makes operation smoothly.
• 【FULLY TESTED & EASY INSTALLATION】- The ac compressor clutch has been examined and tested carefully before its delivery. And the kit without refrigeration oil inside, be aware of it when starting your installation and replacement. If you need to add oil after a long time use, please add pure refrigerant, and should not be added to too much, 70-80% is appropriate.





Fit For:

for Kia Spectra/Sportage 2004-2007;

for Hyundai Tucson 2005-2006





Part Number



•     Advance Auto Parts: DW97370
      Austin Baker: 10362111
      Autocomp Technologies: 1021014
      Autocomp Technologies: 1121014
      Autocomp Technologies: 1221014
      Compressor Works: 639312
      Compressor Works: 639314
      Four Seasons: 158303
      Four Seasons: 97370
      Four Seasons: 98370
      Four Seasons: 98373
      Global Parts Distributors: 5512280
      Global Parts Distributors: 5512343
      Global Parts Distributors: 7512280
      Global Parts Distributors: 7512343
      Global Parts Distributors: 7512775
      For For Hyundai/For For Kia: 977012D700
      For For Hyundai/For For Kia: 977012F100
      For For Hyundai/For For Kia: 977012F110
      NAPA: 255691
      NAPA: 274484
      NAPA: 274488
      NAPA: TEM255691
      NAPA: TEM274484
      NAPA: TEM274488
      Omega: 2021919
      Omega: 2021924
      Omega: 2022273
      Oreilly Auto Parts: 97370
      Ranshu: 140249C
      Ranshu: 140249NC
      Ranshu: 140249NEW
      Ranshu: 140257
      Ranshu: 140257C
      Ranshu: 140257NC
      Ranshu: 140257NEW
      Tech Choice Parts: 22497
      TRAD AUTOMOTIVE: C1830
      TRAD AUTOMOTIVE: C2078
      TRAD AUTOMOTIVE: C2496





Note:

Please make sure the installation site is clean. Or it will cause operating obstruction, making the compressor's temperature very high, and the belt on the clutch may melt.
But you need to add the refrigerant. Please add it to 70-80%. Try not to fill it up. There may be noise if the refrigerant is added too much.


Installation Steps:

1. Once the old compressor has been removed, begin by removing the receiver/drier or accumulator and the expansion valve or orifice tube from the vehicle.
2. Next, flush the condenser and evaporator using a non-oil-based A/C flush. The valve must be removed from the expansion valve system before the evaporator can be flushed.
3. Flush evaporators from inlet to outlet.
4. Install the new receiver drier or accumulator and a new expansion valve or orifice tube.
5. Next, install the new or remanufactured A/C Compressor.
6. Install and tighten the A/C Compressor mounting bolts.
7. Reconnect any electrical connectors to the A/C Compressor.
8. Re-install the refrigerant lines and A/C belt to the A/C Compressor.
9. Reconnect the negative battery cable.
10. Evacuate the A/C system with an A/C servicing machine for at least one hour.
11. Check the system for leaks.
12. If there are no leaks, install the refrigerant charge (Check the A/C system sticker under the hood of the vehicle for the proper amount and type of refrigerant for the system). Then, let the system set for 2 minutes. Doing so will allow the refrigerant to carry the oil and spread it more evenly throughout the system.
13. Start the vehicle’s engine and turn on the A/C system.





Package Included:

As the picture show
