F-16 SPECIAL USAF_ANG_AGGRESSORS_NATO_IDF_KLu_RNLAF_GREECE_UAE_CHILE_SINGAPORE_JASDF
SOFTBOUND BOOK / SPECIAL ISSUE FROM AIR INTERNATIONAL
(132 PAGES)
COMBAT
OPERATIONS (ISRAELI RAID ON THE OSIRIK NUCLEAR REACTOR IN IRAQ, DESERT STORM
FIRST GULF WAR 1990-91, OPERATION NORTHERN WATCH / SOUTHERN WATCH IRAQ,
OPERATION DENY FLIGHT YUGOSLAVIA, SCOTT O�GRADY, OPERATION ALLIED FORCE SERBIA,
OPERATION ENDURING FREEDOM AFGHANISTAN, OPERATION IRAQI FREEDOM)
AIR
DEFENSE FIGHTER ADF F-16 AIR NATIONAL GUARD (LUKE AFB, AIR FORCE RESERVE,
MONTANA AIR NATIONAL GUARD ANG, 56th TFW, DISTRICT OF COLUMBIA ANG, TFTS
TACTICAL FIGHTER TRAINING SQUADRON, SOUTH CAROLINA ANG, MOODY AFB 347TH TFW,
NEW MEXICO ANG, OHIO ANG, NY ANG, COLORADO ANG, OKLAHOMA ANG, ALABAMA ANG,
MINNESOTA AIR NATIONAL GUARD ANG, VERMONT ANG, FLORIDA ANG, CALIFORNIA ANG)
USAF
AGGRESSOR SQUADRONS (F-16C)
ROYAL
NETHERLANDS AIR FORCE KLU KONINKLIJKE LUCHTMACHT F-16A (No.306 SQUADRON VOLKEL,
No.311 SQN, No.312 SQN, No.323 SQN, KONGELIGE NORSKE LUFTFORSVARET ROYAL
NORWEGIAN AIR FORCE F-16A)
HELLENIC
AIR FORCE GREECE
ISRAELI
AIR FORCE IDF NETZ, BARAKS & SUFAS
UNITED
ARAB EMIRATES UAE AIR FORCE DESERT FALCONS BLOCK 60
JAPAN
JASDF MITSUBISHI FS-X / F-2
CHILEAN
AIR FORCE
PRATT
& WHITNEY F100 TURBOJET ENGINE
PODS,
PYLONS AND WEAPONS
APG-66
RADAR
APG-68
WESTINGHOUSE MULTIMODE RADAR
ACES
II EJECTION SEAT
GENERAL
ELECTRIC M61 VULCAN 20mm CANNON
AVIONICS
AND HYDRAULICS BAY
AN/ALE-40
CHAFF AND FLARE DISPENSER CONTROL MODULE
RADOME
(PITOT TUBE, ANGLE OF ATTACK AOA SENSOR)
RADAR
(NORTHROP GRUMMAN WESTINGHOUSE AN/APG-68)
FORWARD
FUSELAGE (IFF ANTENNA, RHAW RADAR AND HOMING WARNING SYSTEM, AVIONICS DOORS,
FORWARD BAY, CANOPY EMERGENCY JETTISON)
CANOPY
20mm
GATLING GUN CANNON / AMMUNITION DRUM
HYDRAZINE
TANK / EMERGENCY POWER UNIT
FUEL
CELL ACCESS
AIR-TO-AIR
REFULEING SLIPWAY DOOR
EXTERNAL
REINFORCEMENT PLATES
WINGS
(FLAPERONS, LEADING EDGE, RHAW ANTENNA, STROBE LIGHTS, WEAPONS HARDPOINTS)
VERTICAL
STABILIZER (RUDDER, ANTI-COLLISION LIGHT, INFRA-RED EMMITER)
HORIZONTAL
STABILIZER (STATIC WICK LINES)
SPEED
BRAKES
PRATT
& WHITNEY F100-PW-229
ENGINE
BAY
FUSELAGE
BOTTOM (ARRESTOR HOOK, UHF ANTENNA, VENTRAL FINS, JET FUEL STARTER, SINGLE
POINT REFUELING PORT, INSPECTION DOORS)
CHAFF
/ FLARE HOUSING
WHEEL
/ TIRE ASSEMBLY
LIGHTWEIGHT
MAIN GEAR / HEAVYWEIGHT MAIN GEAR (GEAR WELLS, GEAR DOORS, NOSE LANDING GEAR)
ENGINE
AIR INTAKE (MCID �BIGMOUTH� & NSI NORMAL SHOCK INLET �SMALLMOUTH�)
ACES
II EJECTION SEAT
COCKPIT
(INSTRUMENT PANEL, HEADS UP DISPLAY HUD, AOA INDEXER, MFD MULTI-FUNCTION
DISPLAYS, RHAW SCOPE, UFC UP FRONT CONTROLLER, CNI COMM NAV IFF, DED DATA ENTRY
DISPLAY, ICP INTEGRATED CONTROL PANEL, FLCS FLIGHT CONTROL SYSTEM, HOTAS HANDS
ON THROTTLE SYSTEM, SIDE CONTROL STICK, MULTI-PIECE GLARE SHIELD)
SEAD
SUPPRESSION OF ENEMY AIR DEFENSES HARM MISSILE
INTERNAL
CANOPY STRUCTURE
EXTERNAL
FUEL TANKS
STATION
4/6 PYLON
STATION
3/7 PYLON
AIR-TO-AIR
MISSILE RAILS
AN/ALE-50
TOWED DECOY
AIM-9
SIDEWINDER / CATM-9M SIDEWINDER / AIM-9X SIDEWINDER
AIM-120
AMRAAM
TRIPLE
EJECTOR RACK (LOW DRAG GENERAL PURPOSE �DUMB� BOMBS, Mk82 500LB)
ROCKET
PODS
CREW
BOARDING LADDER
BLOCK
50/52
WEAPONS
AND STORES (AIR-TO-AIR MISSILES, GROUND-ATTACK MISSION)
