Volume ml:50
Structure material :304/316 stainless steel
Design temperature °C:350
Rising and cooling rate °C/min:s5
Design pressure Mpa:22
Stirring speed r/min:0-1800
Heating power Kw:0.7
Heating method: modular electric heating
Mixing method: internal magnetic mixing
Valve: standard with 2 (one inlet, one outlet)
Explosion-proof device: selected according to pressure requirements
Pressure gauge: according to the explosion-proof disc pressure selection,
Temperature hole: standard size 4MM


1.Motor: Magnetically coupled stirring motor stirred samples in the tank
2.Operating handle: easy to install and remove the kettle cover
3.Motor interface: coupling mixing motor
4.Safety seat: Install the fuse
5.Temperature sensor port: Connects to a temperature sensor
6.Circulation port: connect cooling water to cool the shaft
