Type: AM-OLED, OLED

Pixel Format: 1728(RGB)×2368 217PPI

Configuration: Sub-Pixel Rendering

Active Area: 164.7(H)×225.69(V) mm

Outline Dim.: 174.66(H)×238.26(V) ×2.6(D) mm

Luminance: 350 cd/m² (Typ.)

Contrast Ratio: 24000:1 (Min.) (TM)

View Direction: Symmetry

Response Time: 2 (Max.)(Tr+Tf)

Viewing Angle: 80/80/80/80 (Typ.)(CR≥1000)

Support Color16.7M 100% DCI-P3

Light Source: self

Designed For: Pad & Tablet

Frame Rate: 60Hz

Touch Panel：On-Cell Touch

D-IC Detail: Built-in RM69380

Interface Type: MIPI (2 ch, 4 data lanes) , 61 pins Connector

Operating Temperature: -20 ~ 70 °C ;

Storage Temperature: -40 ~ 85 °C

TP Signal: I²C

Packing List and Note

11" AMOLED Display+ HDMI Driver Board + Flex Cable
