Product Type: Starter |
Replaces: 0745-052 0745-257 0745052 0745257 |
  • Starter Type: PMDD |
  • Volts: 12 |
  • Teeth On Drive: 9 |
  • Rotation: Clockwise |
  • Source: Aftermarket
Over 30,000 aftermarket & original parts
Open 24 Hours
8-6 EST SALE SUPPORT
English/Español/Call Us Today

Starter Arctic Cat Z 370 LX ES Z 440 Sno-Pro Panther 370 0745-030 0745-018

Replaces Part Numbers & Specifications

OEM PART NUMBERS:
• Arctco: 0745-052
• Arctco: 0745-257
• Arctco: 0745-030
• Arctco: 0745-018
• Arctco: 0745-357 (replaced by 0745-434)
• Arctco: 0745-434 (current number)
• Arctco: 6639-631
• Arctco: 0745-395
• Arctco: 0745-382
• Arctco: 0745-376
• Arctco: 0745-358
• Arctco: 0745-351
• Arctco: 0745-331
• Arctco: 0645-064

SUPERSESSION CHAIN:
• 0745-052 → superseded by 0745-257 → superseded by 0745-357 → superseded by 0745-434
• 0745-018 → superseded by 0745-030 → superseded by 0745-357 → superseded by 0745-434

SPECIFICATIONS:
• Type: Starter Motor
• Voltage: 12V
• Rotation: CW (Clockwise)
• Teeth: 9
• Gear OD: 29.1mm / 1.146in
• Weight: 6 lbs / 2.72 kg
• Brush Type: Carbon
• Torque: 1.74 Nm
• Cycle Rating: 10000
• Manufacturer: Johnson Electric
• Dimensions: Length 183mm (7.2in), Width 78mm (3.1in), Height 78mm (3.1in)
• Mounting Hole Distance: 90mm (3.5in)

Product Notice

As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.



ARCTIC CAT SNOWMOBILE APPLICATIONS:

PANTERA (431cc):
• Pantera 440 (431cc) - 1988, 1989, 1990, 1991, 1992
• Pantera 550 (550cc) - 1993, 1994

PANTHER (339-431cc):
• Panther 340 (339cc) - 1998, 1999, 2000
• Panther 370 (367cc) - 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008
• Panther 440 (431cc) - 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002
• Panther 440 Deluxe (431cc) - 1991, 1992, 1993, 1994, 1995, 1996
• Panther 440 ESR (431cc) - 2001
• Panther 440 LC (431cc) - 1996
• Panther 440 Mountain Cat (431cc) - 1990, 1991

PROWLER (431cc):
• Prowler 440 (431cc) - 1990, 1991, 1992, 1993, 1994
• Prowler 440 2-Up (431cc) - 1991, 1992, 1993, 1994
• Prowler 440 Mountain Cat (431cc) - 1991, 1992
• Prowler 440 Special (431cc) - 1991, 1992
• Prowler 550 2-Up (550cc) - 1995

PUMA (339cc):
• Puma 340 (339cc) - 1994, 1995, 1996, 1997
• Puma 340 2-Up (339cc) - 1994, 1995, 1996, 1997
• Puma 340 Deluxe (339cc) - 1994, 1995, 1996, 1997

SUPER JAG (431cc):
• Super Jag 440 (431cc) - 1989, 1990, 1991, 1992

Z 370 (367cc):
• Z 370 (367cc) - 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007
• Z 370 ES (367cc) - 2000, 2001, 2002, 2003
• Z 370 ESR (367cc) - 2003
• Z 370 LX (367cc) - 2004, 2005, 2006, 2007

Z 440 (431cc):
• Z 440 (431cc) - 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006
• Z 440 ES (431cc) - 2000, 2001, 2002, 2003
• Z 440 ESR (431cc) - 2003
• Z 440 LX (431cc) - 2004, 2005, 2006
• Z 440 Sno-Pro (431cc) - 1999, 2000, 2001, 2002, 2003
