Receiver DUMBORC P6F 2.4G 6CH Radio Control System Receiver for Domborc RC X4 X5 X6 Transmitter
Features:
1.Receiver voltage range: 3.3V-10V, working current 30mA, support high-voltage steering gear.How to Match Code With Transmitter:1. Put the transmitter and the receiver close to each other within 50 centimeters.
2. Turn on the transmitter, then power on the X6F/X6FG.
3. There is a black button on the P6F/P6FG, press the binding button twice in two seconds and release, receiver light start blinking, after about blinking 8 times, match code success then receiver signal LED always on!
Description：
DUMBORC P6F 2.4G 6CH Radio Control System Receiver for Domborc RC X4 X5 X6 Transmitter miniZ 1/28 1/24 RC Car.
Specifications:
Item Brand:DUMBORC
Item Number:P6F
X6F : without Gyro
X6FG : with Gyro
Item Name:Receiver
Material:plastic and electronic components
Color:Black
Channel:6CH
Model:Car/boat/tank
Modulation Mode: GFSK
Spread Spectrum: FHSS
Control Distance: More than 400 meters
Voltage Range:3.3-10V
Working Current:30mA
Compatible with:X6 Transmitter
Product Size:35*20*13mm, antenna length 106 mm
Package information:
Package size:5*3*2cm
Package weight:23g
Polybag package
Package Included:
1 x Receiver
Only the above package content, other products are not included.
1.Due to the difference between different monitors,the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures.
2.Due to the manual measurement and different measurement methods, please allow 1-3mm deviation.Thanks!
