Hikvision 16ch 16 POE Security System Kit 6MP Acusense 2Way Audio IP Camera Lot

>APP : Danale ( IOS,Android), support download by QR code
>Search Tool：SADP (HIKVISION)
>Warranty: 3 Years
>If there is any problem with use, please contact with us at any time. we have very professinal engineer, can help you set online.
>>>The Camera is Hikvision Compatible, support Hikvision Protocol. can plug and play with Hikvision NVR
>>> The NVR is Hikvision original,support upgrade.
>>> All the items are with 3 years warranty, if there is any problem after purchased, please contact us for help.
Notes:
>>When connect with hikvision NVR, only have 1-way audio for microphone function, speaker function can't use.
>>Only with our Uniview NVR can use 2 way audio.When you use mobile phone,it can use 2 way audio.


Features

6MP YC2265I-ISU Acusense Turret IR PoE IP Camera

> 1/3" CMOS sensor
>  6MP realtime resolution 3072x2048
>  Low illumination 0.01Lux
>  Day/Night, AWB/MWB,BLC, HLC, 2D/3D-DNR,Shutter, IR-CUT
>  D-WDR,Mirror, rotate, Defogging
>  Multiply Style OSD Overlay,Motion Detection, Privacy Mask
>  RTSP and O-N-V-I-F 17.06 compatible with many third-party NVR
>  Smart264/Smart265 dual-stream media server
>  Easy-to-use P2P Cloud service
>  Support user authentication, video data encryption
>  Support Alarm Snapshot to E-mai1 and FTP
>  Multiply WEB browser IE,Firefox 32bit ESR, PC Client, M0bi1e APP remote access
>  RJ45 100mbps network port, IEEE802.3af PoE
>  Lightning protection 4000V
>  Strong water-proof housing, IP66
>  2 pcs Array IR Leds, IR distance 20-30 meters
>  2.8mm fixed lens
>  Human body detection, Vehicle detection
>  Two-way Audio, SD card slot (Max. 256GB)

16-ch 1U 16 PoE 4K NVR

  • Up to 16-ch IP camera inputs
  • H.265+/H.265/H.264+/H.264 video formats
  • Up to 2-ch@8 MP or 4-ch@4 MP or 8-ch@1080p decoding capacity
  • 1 HDMI and 1 VGA interfaces, both interfaces support independent video output
  • 2 SATA interfaces for HDD connection (up to 10 TB capacity per HDD)
  • Up to 160 Mbps incoming bandwidth
  • Plug-and-play with 16 power over Ethernet (PoE) interfaces

Specification
YC2265I-ISU
ModelYC2265I-ISU
Camera
Image Sensor1/3" CMOS
Effective Pixels6 megapixels
Electronic ShutterAUTO, 10-10000/min
Min. Illumination0.01Lux-F1.2(AGC ON), 0Lux IR on
Day/NightAuto/Color/(B/W)/Timing
WDRDigital WDR
White BalanceAuto/Manual
BLC /HLCSupport
DNR2D/3D DNR
OtherAGC,Motion Detection,Privacy Mask,Flip ,OSD overlay
Encode
Video StandardSmart264/Smart265
Video ResolutionMain Stream:
25fps-6MP(3072x2048)/25fps-5MP(2592x1944)/4MP(2592x1520)/3MP, 30fps-1080P/720P
Sub stream: 25fps-D1/VGA/360P/CIF, etc.
Video Bitrates512Kbps - 12Mbps, VBR/CBR
Audio StandardG.711-u/G.711-a
Built-in MicYes
OSD OverlayTitle and Time overlay
IR Led
IR Led2 pcs Array IR Led
IR Distance20-30M
Lens
Focal length2.8mm fixed lens
Optional Function
PoE, two-way Audio, SD card slot (Max. 256GB), Vehicle & human body detection
Network Services
ProtocolHTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS, etc.
P2PYes
WebIE , Firefox (32bit esr), etc.
MediaCMS, Android, IOS
O-N-V-I-F17.06 compatible
General
Network Port1-RJ45, 100Mbps, POE optional
Power SupplyDefault: PoE (12V DC ± 10% optional)
Power Consumption< 8 W
Operating Temp.(+60)°C, 10%-90%RH

DS-7616NI-K2/16P NVR
  • Video Parameter
  • Decoding Capability8*1080P
  • Video And Audio
  • IP Video Input16-ch
  • Incoming Bandwidth160 Mbps
  • Outgoing Bandwidth160 Mbps
  • HDMI Output4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
  • VGA Output1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
  • Video Output ModeHDMI/VGA independent output
  • Audio Input1-ch, RCA (2.0 Vp-p, 1 KΩ)
  • Audio Output1-ch, RCA (Linear, 1 KΩ)
  • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
  • Decoding
  • Decoding FormatH.265/H.265+/H.264/H.264+
  • Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
  • Synchronous Playback16-ch
  • Decoding Capability1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
  • Stream TypeVideo, Video & Audio
  • Audio CompressionG.711ulaw/G.711alaw/G.722/G.726
  • Network
  • Remote Connection128-ch
  • Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
  • Network Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • PoE
  • Interface16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
  • Power≤ 200 W
  • StandardIEEE 802.3 af/at
  • Auxiliary Interface
  • SATA2 SATA interfaces
  • CapacityUp to 10 TB capacity for each HDD
  • USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
  • Alarm In/Out4/1
  • General
  • Power Supply100 to 240 VAC, 50 to 60Hz
  • Consumption≤ 15 W (without HDD and PoE off)
  • Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Working Humidity10 to 90 %
  • Dimension (W × D × H)385 × 315× 52 mm (15.2" × 12.4" × 2.0")
  • Weight≤ 3 kg (without HDD, 6.6 lb.)
  • Certification
  • FCCPart 15 Subpart B, ANSI C63.4-2014
  • CEEN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
