Description:
1.DR25 25PIN Female
DR25 25pin DIP Right Angle Female Adapter Converter Connector
Model:DR25
Amount:5PCS 10PCS
Number of Pins:25PIN
Body Orientation:Right Angle
Gender:Female
Type of row:2 rows


2.DB25 25PIN Female/Male
25 Pin D-SUB Female Male DB25 DB25M Solder Type Connector DB25
Features:
Model:DB25
Amount:5PCS 10PCS
Number of Pins:25PIN
Body Orientation:Straight
Gender:Female/Male
Type of row:2 rows
Connector Series:D-Subminature
Insulator: High temperature
thermoplastic with g.f, UL 94V-0
Contacts: Copper Alloy, t=0.20mm
Shell: Spcc, t=0.30mm
Current Rating:1A MAX.
Dielectric Withstanding
Voltage:750 V (ac) For 1 Min
2.3 Contact Resistance:30mΩ MAX.
2.4 Insulation resistance: 1000 MW Max
2.5 Total mating force 7.0 Kgf Max
2.6 Total unmating force: 1.5 kgf Min
2.7 Temperature range: -50℃ ~85℃


3.DB37 37PIN Female/Male
5/10PCS DB37 Female Male Socket 37Pin Dual Row Blue Connector Port Socket
Model:DB37
Amount:5PCS 10PCS
Number of Pins:37PIN
Body Orientation:Straight
Gender:Female Male
Type of row:2 rows


4.DB15 15PIN Female/Male
Description
100% Brand new, never used
DB15 D-Sub 15pin Female Male 3 rows Solder type connector, for PC use
Tin plated steel shell
Used for the construction of serial cables, parallel cables, and various gaming applications.
Model:DB15
Amount:5PCS 10PCS
Number of Pins:15PIN
Body Orientation:Straight
Gender:Female Male
Type of row:3 rows
Type: Solder Type
