Product Description
Equipment Performance Description and Features
1. Sealing diameter: φ40 - φ130mm; Sealing height: 60 - 220mm;2. Stable production efficiency: 35 cans per minute;
3. An additional air compressor is required. The air compressor should have a power of 3KW or above, with a supply pressure of 0.6Mpa;
4. The main material of the overall appearance is stainless steel 304, with a thickness of 1.5mm;
5. Four rollers are used for sealing, ensuring more uniform force distribution and achieving international standard sealing performance;
6. Intelligent program design and touch screen control are adopted, making the operation and settings simple and convenient;
7. The rollers are imported from Taiwan, made of SKD31 Japanese mold steel, with a positive and negative design, and the lifespan exceeds 5 million times of sealing;
8. The absence of a lid and the detection of faults for stopping the machine are set, effectively reducing equipment failures;
9. The lower cover can be covered for 200 cans (one barrel) at a time;
10. Changing the sealing diameter requires replacing the mold, and the replacement and adjustment time is approximately 40 minutes;
11. To change the sealing diameter, you need to replace: pressure head + lower coverer + turntable + guardrail. Different material cans and lids also require changing the sealing roller;
12. Changing the height of the can does not require replacing accessories. It adopts a hand-crank screw design, and the adjustment time is approximately 5 - 10 minutes;
13. Before delivery for use, the equipment undergoes strict testing to ensure its sealing effect and product quality;
14. The defect rate is extremely low: less than one part in ten thousand for iron cans, less than one part in a thousand for plastic cans, and less than one part in two thousand for paper cans;
15. The pressure head is treated by chromium 12 molybdenum vanadium quenching, with a hardness of over 50 degrees, and the service life exceeds 1 million cans;
16. The conveyor belt is 3 meters long, 0.9 meters high, and the width of the chain plate is 114mm;
17. The equipment size is 2.95 meters in length, 0.95 meters in width, and 1.7 meters in height. The packing size is 1.35 meters × 1.20 meters × 1.90 meters;
18. The net weight of the equipment is approximately 500KG, and the gross weight is approximately 550KG;
19. The main motor power is 1.1KW/220V, the conveyor belt motor power is 0.2KW/220V, and the total power is: 1.3KW;
20. The conveyor belt material is nylon POM, and the clamping plate is made of PP board material;
