[1-inch Female Thread] Aluminum Alloy Turbine Flow Meter
Aluminum alloy housing digital turbine flowmeter with a DN25 female threaded connection, flow range 10–166 L/min, pressure rating 1.6 MPa, and measurement accuracy of 1%. Displays instantaneous flow rate, total cumulative flow, and single-cycle cumulative flow. Features a built-in stainless steel turbine and bracket, supports reset calibration, and is suitable for measuring the flow of various liquids.
【1.5-Inch Female Thread】Aluminum Alloy Turbine Flow Meter
Aluminum alloy digital turbine flow meter with a DN40 female thread connection, flow range 33.3–333 L/min, operating pressure 1.6 MPa, and measurement accuracy of 1%. It features instantaneous, total cumulative, and single-cycle cumulative readings, with a built-in stainless steel turbine assembly and button-activated reset calibration, ensuring stable and reliable liquid flow measurement.
[2-inch Female Thread] Aluminum Alloy Turbine Flow Meter
Aluminum alloy housing digital display turbine flowmeter, DN50 internal threaded connection, flow rate 66.6–666 L/min, pressure rating 1.6 MPa, measurement accuracy 1%. Supports instantaneous flow, total cumulative, and single-cycle cumulative display; features a built-in stainless steel turbine and bracket; resettable calibration; suitable for medium-to-high flow liquid measurement applications.
【3-Inch Female Thread】Aluminum Alloy Turbine Flow Meter
Aluminum alloy digital display turbine flow meter, DN80 female thread, flow rate 166.6–1,666 L/min, maximum pressure rating 1.6 MPa, measurement accuracy 1%. Large-screen digital display showing instantaneous flow rate, total cumulative flow, and single-cycle cumulative flow; built-in stainless steel turbine support bracket; button-operated reset and calibration; meets high-flow liquid metering requirements.
[4-Fen Female Thread] Aluminum Alloy Turbine Flow Meter
Aluminum alloy digital turbine flowmeter, DN15 internal thread, flow rate 10–100 L/min, pressure rating 1.6 MPa, measurement accuracy 1%. Displays instantaneous flow rate, total cumulative flow, and single-cycle cumulative flow; features a built-in stainless steel turbine assembly and supports reset calibration; designed for liquid flow measurement in small-diameter pipes.
[6 mm Female Thread] Aluminum Alloy Turbine Flow Meter
Aluminum alloy housing digital display turbine flow meter, DN20 female threaded connection, flow rate 10–133 L/min, working pressure 1.6 MPa, measurement accuracy 1%. Displays instantaneous, total cumulative, and single-cycle cumulative flow rates; features a built-in stainless steel turbine and bracket; button-activated reset and calibration; designed for liquid measurement in small-diameter pipes.
[6-Minute Male Thread] Aluminum Alloy Turbine Flow Meter
Aluminum alloy digital turbine flowmeter, DN20 male thread, flow rate 10–133 L/min, pressure rating 1.6 MPa, measurement accuracy 1%. Displays instantaneous, total, and single-cycle flow rates; features a built-in stainless steel turbine assembly; comes with matching male threaded fittings; supports reset calibration; convenient for installation in external piping systems.
【1-Inch Male Thread】Aluminum Alloy Turbine Flow Meter
Aluminum alloy housing digital display turbine flow meter, DN25 male thread connection, flow rate 10–166 L/min, working pressure 1.6 MPa, measurement accuracy 1%. Digital display of instantaneous, total cumulative, and single-cycle cumulative flow rates; built-in stainless steel turbine bracket; comes with external threaded fittings for easy installation; designed for liquid flow measurement.
[1.2-inch External Thread] Aluminum Alloy Turbine Flow Meter
Aluminum alloy digital turbine flowmeter, DN32 external thread, flow rate 33.3–333 L/min, pressure rating 1.6 MPa, measurement accuracy 1%. Displays instantaneous, total, and single-cycle flow rates; features a built-in stainless steel turbine assembly and a reducer with external thread, suitable for installation and measurement in corresponding piping systems.
【1.5-inch Male Thread】Aluminum Alloy Turbine Flow Meter
Aluminum alloy housing digital display turbine flow meter, DN40 male thread connection, flow rate 33.3–333 L/min, working pressure 1.6 MPa, measurement accuracy 1%. Large screen displays instantaneous, total cumulative, and single-reading cumulative flow rates; features a built-in stainless steel turbine and bracket, along with an external threaded connector for easy on-site installation and removal.
[2-inch External Thread] Aluminum Alloy Turbine Flow Meter
Aluminum Alloy Digital Turbine Flow Meter, DN50 external threaded, flow rate 66.6–666 L/min, pressure rating 1.6 MPa, measurement accuracy 1%. Displays instantaneous, total cumulative, and single-cycle cumulative flow rates. Features a built-in stainless steel turbine support bracket and matching external threaded fittings, suitable for liquid measurement in medium- to high-flow pipelines.
