Description

Notice: Please double-check the OE number before purchase to ensure fitment. You may provide last 8 digits of your VIN to a local authorized dealer on your own to help confirm OE reference number, if available.

Fit for Engine:
For Subaru Impreza WRX 2.5L Gas 2009-2014(not fit the STI.)
For Subaru Forester 2.5XT 2007-2011

Turbo Model: RHF55,VF52

Turbo Part Number:

14411AA800,14411-AA800,1-4411-AA800,
40-30186 R,VF52, VF55,

Specification:

Compressor Wheel Diameter: 46/59mm
Turbine Wheel Diameter: 47/51 mm
Exhaust Inlet Flange: 3 Bolts
Exhaust Outlet Flange: 5 Bolt
Nozzle Area: 7cm

Turbo Model: RHF5H, RHF5H 09 098E
Engine Code: 6MT, EJ25 2.5 GT
Cooling Type: Water & Oil Cooling
Thrust Bearing: 360 Degrees
Horsepower: 320HP
Bearing Type: Floating Bearing
Turbo Type: Individual
Condition: 100% Brand New
Accessories: You will get exactly as shown in the picture above
Package Weight: 6740g
Package Size: 30*28*24cm

Features

* Product Material
1. Turbine housing: Ductile iron QT450-10- temperature resistant up to 700℃
2. Steel turbine wheel: K418 alloy - high oxidation stability and resistance up to 900℃
3. Compressor housing: ZL104 aluminum with lightweight
4. Compressor wheel/blades: Cast aluminium blades – superior air tightness & corrosion resistance

* Product
1. OEM-quality and size with little modification
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance

* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS VSR3
2. G3-min-Flow VNT Turbo testing
3. Advanced Actuator Tester/Programmer

NOTE:

* Please confirm your original turbo PART NUMBER before Purchasing
* Professional installation is highly recommended
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
