COMPATIBILITY:
1988 Chevrolet Camaro Base V8 5.0L
1982-1986 Chevrolet Camaro Berlinetta V8 5.0L
1985-1990 Chevrolet Camaro Iroc-Z V8 5.0L
1987-1990 Chevrolet Camaro Iroc-Z V8 5.7L
1987 Chevrolet Camaro LT V8 5.0L
1990-1992 Chevrolet Camaro RS V6 3.1L
1989-1992 Chevrolet Camaro RS V8 5.0L
1992 Chevrolet Camaro RS Heritage Edition V6 3.1L
1992 Chevrolet Camaro RS Heritage Edition V8 5.0L
1982-1987 Chevrolet Camaro Sport V8 5.0L
1982-1986 Chevrolet Camaro Sport L4 2.5L
1982-1987 1991 1992 Chevrolet Camaro Z28 V8 5.0L
1991 1992 Chevrolet Camaro Z28 V8 5.7L
1992 Chevrolet Camaro Z28 Heritage Edition V8 5.0L 5.7L
1982 Chevrolet Camaro Z28 Indianapolis 500 Pace Car V8 5.0L
1989 Chevrolet P20 Base V8 5.7L
1989 Chevrolet P20 Step-Van V8 5.7L
1989 1990 Chevrolet P30 Base V8 5.7L
1989 1990 Chevrolet P30 Step-Van V8 5.7L
1989 GMC P2500 Base V8 5.7L
1989 GMC P2500 Value Van V8 5.7L
1989 1990 GMC P3500 Base V8 5.7L
1989 1990 GMC P3500 Value Van V8 5.7L
1990-1992 Pontiac Firebird Base V6 3.1L
1982-1992 Pontiac Firebird Base V8 5.0L
1887 1988 Pontiac Firebird Base V8 5.7L
1982-1986 Pontiac Firebird Base L4 2.5L
1989-1992 Pontiac Firebird Formula V8 5.0L 5.7L
1982-1986 Pontiac Firebird S/E V8 5.0L
1982-1984 Pontiac Firebird S/E L4 2.5L
1982-1992 Pontiac Firebird Trans Am V8 5.0L
1987-1992 Pontiac Firebird Trans Am V8 5.7L
1989 Pontiac Firebird Trans Am V6 3.8L
1989-1992 Pontiac Firebird Trans Am GTA V8 5.0L
1989-1992 Pontiac Firebird Trans Am GTA V8 5.7L
1989 Pontiac Firebird Trans Am GTA SE V6 3.8L
RADIATOR SIZE:
Core Size: 26.26" *16.46" *1.73"(667*418*44mm)
Overall Size: 32" *19.5" (Include the inlet outlet)
Rows: 4
Inlet/Outlet: 1.26"/1.57"(32/40mm)
Trans Cooler: Included(￠26*290*M12*1.25（Z）)
Package included: 1 piece Aluminum Radiator in Cartoon Box+Fan
(Please double confirm your radiator measurements before ordering)
RADIATOR ADVANTAGE
*INCREASED cooling capacity & LOWER temperature( 35 - 45% )
*DIRECT Bolt-On OE Fitment or Replacement
* LESS weight & MORE resistant
*1 YEAR Warranty Against Manufacturing Defect
*TUBE and FIN design & FULL T-6061 aluminum
*EXTRA thickness of bracket and tubes to maintain constant geometry at ALL times.
* IMPROVE handling, stability at high speed and cornering, hence safer driving.
* Minimize the weight transfer of the vehicle body, BETTER traction during cornering.
*LUXERAD aluminum radiator is designed to provide maximum cooling
efficiency to PREVENT premature engine failure.
HOW TO REPLACE THE RADIATOR:
1. Disconnect the battery.
2. Drain the radiator fluid into a suitable container.
3. Remove the old radiator:
-Take off any plastic covers around the radiator.
-Disconnect the electrical connector to the fan, and unbolt and remove the fan assembly.
-Disconnect the radiator hoses from the radiator.
-Disconnect the transmission cooling lines from the bottom of the radiator.
-Remove any clamps, brackets, or screws holding the radiator inside its frame.
-Lift the radiator up and out of the car.
4. Install the new radiator:
-Slide the new radiator into place.
-Connect any clamps or brackets that hold the radiator in place.
-Connect the transmission cooling lines carefully.
-Connect the engine cooling hoses to the radiator.
-Replace the fan and fan shroud.
-Reconnect the fan electrical connection.
-Replace the plastic covers.
5. Fill the radiator with fluid.
6. Check your work to make sure that there are no leaks.
(Tools need to be prepared: Screwdrivers, Wrenches, Drain pan)
Note: Do please keep children and pets away when replacing the radiator)
NOTE:
1. Project operation, the vehicle normal temperature 60 to 80 degrees.
2. Add detergent if the tank is too full can take some antifreeze.
HOW TO CLEAN RADIATOR:
1. Start the vehicle, to rise to normal temperature. Slowly open the tank
cover, the fluid shake from the tank after filling the mouth, the cleaner can
be mixed with any brand of coolant. Idle running not less than 15 minutes,
not cleaning vehicles not less than 30 minutes for two years. And then discharge
coolant, flush water tank, until out of clear water, suitable for any water cycle system.
2. After cleaning, after waiting for pipeline rehabilitation add fluid to water tank,
and inject new coolant and water purification.
