UNIT Thermal2 is a data processing MCU-equipped MLX90640 thermal imaging acquisition unit. It has 32x24 imaging pixels, a field of view of 110°x75°, and a temperature measurement range of -40°C to 300°C. The MCU uses ESP32, which is capable of high and low temperature alarms, average, maximum and minimum values reading, and data caching via data processing. The board integrates with a buzzer, RGB indicator, function and reset buttons, and communicates with the host computer through I2C. This product can be used together with the host computer or separately, and is applicable for temperature measurement and abnormal alarms.

Features

MCU:ESP32-PICO-D4
MLX90640 Infrared (IR) Sensor
Reset buttom
Passive buzzer
Integrated programmable RGB LED
GROVE I2C/HY2.0-4Pinterface
Programming platform: Arduino/UIFlow

Includes

1x THERMAL2 Unit
1x HY2.0-4P cable

Applications

High-precision non-contact temperature measurement
Motion detection
Visual infrared thermometer
DIY Projects
