Condition: BRAND NEW IN ORIGINAL PACKAGING

Warranty: 1 YEAR MANUFACTURER

Features and Functions:

The HB 46 II 4A is 6-Channels DSP with 31-bands EQ and integrated 4-Channels Class-AB Amplifier. It has 4-Channels High-Level inputs and 6-Channels RCA outputs, plus 2-Channels RCA inputs. We also add a quality HD Bluetooth for music streaming and the Music Player function to be activated via USB memory. With the optional Remote you can also control the main and subwoofer volume, select Presets and input Source, and switch to previous or next song with the Music Player, directly from your dashboard.

Technical Specifications:

• DSP Channels: 6

• High Level Inputs: 4-Channels

• RCA Inputs: 2-Channels

• RCA Outputs: 6-Channels

• RMS Power (4Ω): 4 x 23W

• RMS Power (2Ω): 4 x 35W

• MAX Power: 4 x 70W

• Amplifier Class: AB

• BT Streaming: Yes (included)

• Music Player: Yes (App)

• DSP Tools: PC and APP

• DSP Equalizer: 31-Bands

• Input Choice: Aux, BT, Hi-Lev, Player, OTG

• I/O Mixing Matrix: Yes

• Crossover Type: Butterw., Bessel, Linkwitz-Riley

• Crossover Slope: 6 ~ 48 dB/Oct

• Freq. Response: 20Hz - 20KHz

• S/N Ratio: > 100dB

• THD: < 0.05%

• Supply Voltage: 12V -14.4V

• Input Impedance:

  • 20 KOhm (Low)

  • 22 Ohm (High)

• Signal I/O Range:

  • RCA Input 6Vpp

  • RCA Output 3Vpp

  • High-Lev. 12Vpp

• Power Supply Cons: DC 9V-16V < 0.1W

• Unit Dim. (mm):

  • 160 (L)

  • 126 (W)

  • 45.5 (H)
