Radiator Aluminum 1522 For 1992-1999 Chevy GMC C K 1500 2500 3500 5.0L 5.7L 7.4L

We also offer a variety of Auto parts for sale. If you have any other product needs, please feel free to contact us via eBay message

1pc Radiator For 1994-2004 Chevy GMC C/K 1500 2500 3500 Tahoe Yukon CU1693

Specifications

Length(cm): 106.0, width(cm): 12.0, height(cm): 56.0

Weight(kg): 7.8

Material: Plastic Aluminium

Color: Silver

Placement on Vehicle: Front

Core Material: Aluminium

Tank Material: Plastic

Bottom Header: 3.18" x 18.48

Core Height (IN): 17.24

Core Length (IN): 33.98

Core Thickness (IN): 1.26

Inlet Diameter (IN): 1.3

Outlet Diameter (IN): 1.57

Top Header: 3.18" x 18.48

Interchange Part Numbers

CU1693

GM3010233

GM3010235

GM3010237

RAD1522

1693

1522

1792

2551

52465838

52465839

52491626

Fitment

1999 - 2000 Cadillac Escalade 5.7L
1994 Chevy Blazer V8 5.7L
1996 - 1999 Chevy C1500 5.0L
1994 - 1999 Chevy C1500 5.7L
1996 - 1998 Chevy C2500 5.0L
1994 - 2000 Chevy C2500 5.7L
1995 - 2000 Chevy C35 5.7L
1994 - 2000 Chevy C3500 5.7L
1996 - 1999 Chevy K1500 5.0L
1994 - 1999 Chevy K1500 5.7L
1997 - 1998 Chevy K2500 5.0L
1994 - 2000 Chevy K2500 5.7L
1994 - 2000 Chevy K3500 5.7L
2001 - 2002 Chevy Silverado 2500 5.7L
2001 - 2004 Chevy Silverado 3500 5.7L
1995 - 2000 Chevy Tahoe 5.7L
1996 - 1999 GMC C1500 5.0L
1994 - 1999 GMC C1500 5.7L
1996 - 1998 GMC C2500 5.0L
1994 - 2000 GMC C2500 5.7L
1994 - 2000 GMC C3500 5.7L
1996 - 1999 GMC K1500 5.0L
1994 - 1999 GMC K1500 5.7L
1998 GMC K2500 5.0L
1994 - 2000 GMC K2500 5.7L
1994 - 2000 GMC K3500 5.7L
1994 - 2000 GMC Yukon 5.7L

Features

Built to strict quality control standards 100% factory tested

ISO9001
IATF 16949
EAC

Easy Installation，100% Compatible with OEM Parts, meets Original Equipment Manufacturer (OEM) Standards

Mechanically tested prior to leaving the factory ensures optimal performance and enhanced durability.

Perfect match for the original car.

The Core was made from high quality Aluminum.Effective heat dissipation.

Good sealing.

Direct Replacement, easy to be installed

Attention

1. The radiator cap that has not passed the test can’t release the pressure when it reaches the pressure value.
2. The damaged thermostat is unable to carry out a large cycle, resulting in a continuous increase in the radiator pressure.
3. The radiator fan does not turn, resulting in high temperature in the water tank.
4. Drain the air from the cooling system. Refer to the user manual or repair manual.
5. Please refer to owner's manual to add coolant.
6. Do not open the hood until the steam has subsided. The engine compartment may be very hot, causing serious injuries such as burns.
7. Please stop the vehicle immediately, when “ENGINE OVERHEAT/High Temperature” shows on the dashboard or steam comes out from under the hood.
8. Keep hands and clothing (especially a tie, a scarf) away from the fans and belts. Failure to do so may cause the hands or clothing to be caught, resulting in serious injuries.
9. Do not loosen the radiator cap while the engine and radiator are hot. Serious injuries, such as burns, may result from hot coolant and steam released under pressure.

Note

1.It will be better if you can check with that above chart to make sure if this radiator will fit your vehicle.
2. The radiator cap that has not passed the test can't release the pressure when it reach the pressure value.
3. The damaged thermostat is unable to carry out a large cycle, resulting in a continuous increase in the radiator pressure.
4. The radiator fan does nont turm, resulting in highh temperature in the water tank.
5. After loading the product on your vehicle and adding the coolant, tighten the rotary cover and leave your vehicle idling for 10-20 minutes. After completely cooling the coolant, open the cover and fill the product with coolant. Please make sure there is no gas in the product.
6. Before you start up your vehicle, please make sure there is coolant in the radiator.
