R-SPS6010 60V 10A Digital Adjustable DC Power Supply laboratory power supply 4-bit display Voltage Regulator For iPhone Repair
|
Modle |
R-SPS6010 |
|
The out voltaage |
0～60V |
|
Output current |
0～10A |
|
Input voltage |
230V+10%; 50Hz (115V+10% 60Hz) |
|
Operating temperaturev |
0°C～40°C; （Relative humidity: <80%RH） |
|
storage temperature |
；－10°C～70°C; （relative humidity: <70%RH） |
|
Constant pressure state |
Voltage stability ≤0.1%+3mV Low voltage: 0.2%～0.3%+3mV |
|
Load stability≤0.5%+3mV |
|
|
Ripple noise: ≤30mVrms (effective value) |
|
|
Constant current state |
Current stability≤0.2%+3mA |
|
Load stability≤0.2%+3mA |
|
|
Ripple noise: ≤20mAems (effective value) |
|
|
Display accuracy |
0.5%+2 words |
|
display resolution |
Voltage: 00.01V Current: 0.001V |
|
Product Size |
223*92*145mm |
|
Total product weight |
1.5kg |
|
Fuse specifications |
3A (220V input) / 5A (110V input) |
