SICK WTB27-3P2411 Photoelectric Sensor BGS 30-1600mm Range PNP M12 DC
- In Stock: 8
- Brand: Sick
- Condition: Used
- Notes: Previously used item in good condition. Tested and fully functional. May show normal signs of wear from use. We warranty all items for 30 days.
- Model: WTB27-3P2411
- Type: Photoelectric Sensor
- Voltage: 10-30 VDC
- Shelf: P-7
- Response Time: ≤1.5ms
- Part Number: WTB27-3P2411
- Enclosure Type: IP69K
- Manufacturer: Sick
- Full Load Amps:: 40mA
- MPN: WTB27-3P2411
- Switching Frequency: 350HzPhotoelectric Sensor
- Sensing Range: 30mm - 1600mm
- Connection Type: M12 Male Connector, 4-pin
- Media 1 Description: Sick WTB27-3P2411 Fiber Optic Sensors - Photo 1
- Media 2 Description: Sick WTB27-3P2411 Fiber Optic Sensors Image 2
- Media 3 Description: Sick WTB27-3P2411 Fiber Optic Sensors View 3
- Media 4 Description: Sick WTB27-3P2411 Fiber Optic Sensors - Photo 4
- Media 5 Description: SICK WTB27-3P2411 Photoelectric Sensor BGS 30-1600mm Range PNP M12 DC
- Termination Type: M12 Male Connector
- Country of Origin: Germany
The SICK WTB27-3P2411 is a compact photoelectric proximity sensor featuring background suppression technology for reliable object detection. This infrared LED sensor offers adjustable sensing range from 30mm to 1600mm with potentiometer adjustment and PNP complementary output for industrial automation applications.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | SICK |
| Model/Part Number | WTB27-3P2411 |
| Product Type | Photoelectric Sensor |
| Sensor Type | Background Suppression |
| Sensing Range | 30mm - 1600mm |
| Light Source | Infrared LED |
| Wavelength | 880nm |
| Supply Voltage | 10-30 VDC |
| Current Type | DC |
| Current Consumption | 40mA |
| Output Type | PNP |
| Output Current | 100mA Max |
| Response Time | ≤1.5ms |
| Switching Frequency | 350Hz |
| Connection Type | M12 Male Connector, 4-pin |
| Termination Type | M12 Male Connector |
| Housing Design | Rectangular |
| Dimensions (W x H x D) | 24.6mm x 80.6mm x 54mm |
| Housing Material | ABS Plastic |
| Optics Material | PMMA Plastic |
| Enclosure Rating | IP69K |
| Operating Temperature | -40°C to +60°C |
| Weight | 100g |
| Adjustment | Potentiometer |
| Light Spot Size | Ø25mm (at 800mm distance) |
| SICK Part Number | 1025994 |
We warranty all items for 30 days from date of purchase.
Domestic Shipping
All items under 145 lbs ship via USPS Priority Mail, UPS Ground, or UPS Next Day Air. We take pride in proper packaging to ensure your items arrive quickly and safely.
- Orders placed before 12:00 PM EST typically ship same day
- Next Day Air orders must be placed by 3:00 PM EST
- Can ship using your UPS account number upon request
- Tracking numbers sent to your eBay account
Freight Shipping
Items over 145 lbs require freight shipping. We ship LTL and full trailer loads with quotes available prior to purchase.
- Provide: Zip code, commercial/residential location, liftgate needs
- Shipping quotes provided within 24 hours
International Shipping
Available for all items. We assist with customs forms and provide overseas delivery quotes.
Payment
We accept PayPal and all major credit cards through eBay checkout. Payment is due within 3 days of purchase.
Returns
We offer a 30-day return policy. Items must be returned in original condition. Buyer pays return shipping unless item was misrepresented. Refunds processed within 3 business days of receiving returned item.
