Features:

• Advantages: 1. Soft start soft stop. 2. Energy saving. 3. Protect the motor. 4. Stepless speed regulation. 5. Low noise operation
• Six Major Functions: 1. Multi-segment operation: 16-segment programmable multi-speed control. 2. Simple PLC operation: can set up to 16 speeds. Automatic running time can be set for each segment. 3. RS485 communication. 4. Output frequency range: wide range, low frequency mode, 0-300Hz; high frequency mode: 0-3000Hz. 5. PID control. 6. Built-in brake unit(0.75KW-18.5KW)
• Three Major Performances:1. Low noise: carrier frequency 1.0KHz-16.0KHz continuously adjustable to minimize motor noise. 2. Automatic voltage regulation: dynamic voltage regulation, static voltage regulation, and non-voltage regulation can be selected according to requirements. 3. Low frequency and high moment of force: the starting moment of force is twice the rated moment of force within 50HZ and the constant moment of force output
• Nine Protections: Overload protection, overheat protection, overvoltage protection, overcurrent protection, undervoltage protection, phase loss protection, ground protection, short circuit protection, stall protection, flame retardant/ proof/anti-corrosion/anti-salt fog
• Application Range: Used in construction sites, factories, waterwork, hotel communities, baths, central air conditioning water systems, paper machinery factories, shopping mall escalators, farms, sewage treatment plants, fire hospital transportation, machine tools, automation equipment, etc. Application Machine: Used in motors, mixers, ball mills, pumps, cranes, conveyors, air compressors, fans, CNC machine tools

Specification:

• Matching Motor Power: 0.75KW~18KW
• Filter: Built-in Filter
• Control Mode: V/F control, advanced V/F control, V/F separation control, open loop current vector control;
• Analog Input and Analog Output:
• Two analog signal inputs, flexible setting between 0-10V and 0-20MA;
• Two analog signal outputs, 0-10V and 0-20MA optional
• Digital Output: 2 relay outputs and 1 transistor output, up to 55 protocols are available;
• Automatic Voltage Regulation Function: Dynamic voltage regulation, static voltage regulation, and non-regulation can be selected according to requirements to obtain the most stable operation effect;
• Low Noise Operation: carrier frequency 1.0KHz-16.0KHz continuously adjustable to minimize motor noise;
• Acceleration/Deceleration Time Setting: 0.1S-3600S continuous setting, S-type, linear mode optional;
• Protection Level: IP20

Package List:

1 x Frequency Converter
1 x User Manual
