Original Ugoos AM9 Smart TV Box Android 14 Amlogic S905x5 4GB 64GB WiFi BT5.2 1000M HDR Android Set Top Box Media Player
Operation System
Android 14.0
Language
Multi-Language support
CPU
Amlogic S905x5 Quad core ARMv9.0 Cortex-A510 CPU
GPU
Mali G310 V5
NPU
- Neural network accelerator (NNA) with Tensor programmable engine (TPU) architecture
- 512KB Internal RAM and SMMU address re-mapper
- Supports all major deep learning frameworks including Tensorflow, Tensorflow Lite, ONNX, Pytorch, Darknet, MxNet, and Caffe 4,3.2~4 TOPS
RAM
LPDDR4X 4GB
Storage Capacity (Flash)
64GB (EMMC)
WIFI
11a/b/g/n/ac/ax 2T2R IEEE802, Max: 1201 Mbps
Bluetooth
Bluetooth 5.2 Module
The Extended Storage
TF Card (SD2.X,SD3.X,SD4.X, eMMC ver5.0)
Power Supply
TYPE-C 12V/1.67A
HDR
Support
CEC
Support
Interfaces:
HDMI Output
Built-in HDMI 2.1b transmitter including both controller and PHY supporting eARC, CEC, ALLM,VRR, QMS, Dynamic HDR and HDCP 2.2/2.3, 4Kx2K@60fps max resolution output
USB Port
USB A HOST 3.0*3
USB TYPE-C OTG 2.0*1
Optical Output
1*SPDIF
Led Work Light
Support
Network
1*RJ45 1000M (1000M Ethernet Integrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII
interface)
Media Parameters:
Audio Containers
Supports MP3, AAC, WMA, RM, FLAC, Ogg Vorbis, Opus, SRS TruVolume, DTS Optional and programmable with 7.1/5.1 down-mixing
Video Output
Supports all standard SD/HD/FHD video output formats: 480i/p, 576i/p, 720p, 1080i/p and 4KX2K
Video CODEC
− H.266 VVC main 10@L5.2 up to 4Kx2K@120fps
− AV1 MP-10@L5.2 up to 4Kx2K@120fps
− VP9 Profile-2 up to 4Kx2K@120fps
− H.265 HEVC MP-10@L5.2 up to 4Kx2K@120fps
− AVS3-P2 Profile up to 4Kx2K@120fps
− H.264 AVC HP@L5.2 up to 4Kx2K@60fps
− MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)
− WMV/VC-1 SP/MP/AP up to 1080P@60fps − AVS-P16(AVS+)/AVS-P2 JiZhun Profile up to 1080P@60fps
− MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
− MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
− Multiple language and multiple format sub-title video support
− MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
− Supports JPEG thumbnail, scaling, rotation and transition effects
Software Extension
Support Google Play & APK install
Other Parameters:
Remote Control
BT remote with Voice+Gyro
Humidity Environment
5%-90%(No condensation)
Certificate
CE, FCC
OEM Options
Ugoos AM9 available with 4G Lte module/SSD port for OEM orders
Package:
Dimensions
11.6X11.6x2.8 CM
Gift Box Size
15x16x9 CM
Description:
.jpg)
.jpg)
.jpg)
.jpg)














Original Ugoos AM9 Smart TV Box Android 14 Amlogic S905x5 4GB 64GB WiFi BT5.2 1000M HDR Android Set Top Box Media Player
Operation System | Android 14.0 |
Language | Multi-Language support |
CPU | Amlogic S905x5 Quad core ARMv9.0 Cortex-A510 CPU |
GPU | Mali G310 V5 |
NPU | - Neural network accelerator (NNA) with Tensor programmable engine (TPU) architecture - 512KB Internal RAM and SMMU address re-mapper - Supports all major deep learning frameworks including Tensorflow, Tensorflow Lite, ONNX, Pytorch, Darknet, MxNet, and Caffe 4,3.2~4 TOPS |
RAM | LPDDR4X 4GB |
Storage Capacity (Flash) | 64GB (EMMC) |
WIFI | 11a/b/g/n/ac/ax 2T2R IEEE802, Max: 1201 Mbps |
Bluetooth | Bluetooth 5.2 Module |
The Extended Storage | TF Card (SD2.X,SD3.X,SD4.X, eMMC ver5.0) |
Power Supply | TYPE-C 12V/1.67A |
HDR | Support |
CEC | Support |
Interfaces: | |
HDMI Output | Built-in HDMI 2.1b transmitter including both controller and PHY supporting eARC, CEC, ALLM,VRR, QMS, Dynamic HDR and HDCP 2.2/2.3, 4Kx2K@60fps max resolution output |
USB Port | USB A HOST 3.0*3 |
Optical Output | 1*SPDIF |
Led Work Light | Support |
Network | 1*RJ45 1000M (1000M Ethernet Integrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII |
Media Parameters: | |
Audio Containers | Supports MP3, AAC, WMA, RM, FLAC, Ogg Vorbis, Opus, SRS TruVolume, DTS Optional and programmable with 7.1/5.1 down-mixing |
Video Output | Supports all standard SD/HD/FHD video output formats: 480i/p, 576i/p, 720p, 1080i/p and 4KX2K |
Video CODEC | − H.266 VVC main 10@L5.2 up to 4Kx2K@120fps − AV1 MP-10@L5.2 up to 4Kx2K@120fps − VP9 Profile-2 up to 4Kx2K@120fps − H.265 HEVC MP-10@L5.2 up to 4Kx2K@120fps − AVS3-P2 Profile up to 4Kx2K@120fps − H.264 AVC HP@L5.2 up to 4Kx2K@60fps − MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) − WMV/VC-1 SP/MP/AP up to 1080P@60fps − AVS-P16(AVS+)/AVS-P2 JiZhun Profile up to 1080P@60fps − MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) − MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) − Multiple language and multiple format sub-title video support − MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) − Supports JPEG thumbnail, scaling, rotation and transition effects |
Software Extension | Support Google Play & APK install |
Other Parameters: | |
Remote Control | BT remote with Voice+Gyro |
Humidity Environment | 5%-90%(No condensation) |
Certificate | CE, FCC |
OEM Options | Ugoos AM9 available with 4G Lte module/SSD port for OEM orders |
Package: | |
Dimensions | 11.6X11.6x2.8 CM |
Gift Box Size | 15x16x9 CM |
