Product Specifications

1. Overall dimensions: (L 33mm*W 27mm*H 206mm)

2. Net weight: 160g

3. Machine Configuration: see packing list for details

4. power supply:

-Categorised by power supply

Powered by rechargeable battery.

-Rechargeable lithium battery

Nominal voltage: 3.7V, capacity: 2200mAh, battery type: ICR

18650, battery with over-voltage, over-current and short-circuit protection.

- Power Adapter

Input: 100-240V ~ 50/60HZ

Fuse: T1A 250V

Input power: 5VA

Output: 5V 1A

5. LED lamp performance:

5W high power blue LED lamp

Category: Class 1

Wavelength: 400nm～480nm

Inspection Methods: LED light emits when it is used in correct operation, which means it is intact.

Radiation：≧850mW/cm2

Optical effective area of light source：75mm2.

Dental resin materials commonly used in clinical practice can match the wavelength of this light curing.

The commonly used clinical dental resin materials can match with the wavelength of this light curing, such as 3M, Dengsperm and other resins.

6. Operating environment

Ambient temperature: 5℃～40

Relative humidity is not more than 80%.

Atmospheric pressure: 75kPa ~ 106kPa

1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color which is showed on the pictures.

2. Please forgive 1 cm/0.39''-3 cm/1.18'' measuring deviation due to manual measurement.
