60 Degree Gloss Meter Tester Glossmeter 0~200GU For Automobile Paint Ink Coating
Introduction:
- Gloss meter features with 60° angle, manufactured according to ISO2813 and GB/T 9754. It is also compatible with international standards of ASTM D523, ASTM D2457.
- Gloss meter is widely used to test glossiness in these industries, such as automobile, paint, ink, stoving varnish, coating, wood products; marble, granite, vitrified polished tile, pottery brick and porcelain; plastic, paper; hardware industries, etc.
Features:
- 60° angle for semi gloss
- Concise appearance, feel good
- Display 3 sets of measurement data, good for comparison
- Built-in lithium ion rechargeable battery
- Basic model measurement can meet basic glossiness testing requirements
- One button for all angles measurement at the same location
- Comply with international standards
- Stable performance, easy to read data.
Specification:
- Model: Economic Gloss Meter
- Measuring angle: 60° Comply with standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D
- Measuring spot (mm): 60°: 9X15
- Measuring range: 0~200GU
- Repeatability: ±1GU
- Reproducibility: ±1GU
- Measurement Standard: Conform with JJG696 first class glossmeter working requirement
- Chromaticity Corresponding: Corresponding with CIE 1931(2°) under CIE C light source
- Errors: ±1.5 , ± 1.5%
- Measurement time: 0.5s
- Size: LXWXH : 160X75X90mm
- Weight: approx. 350g
- Language: Simplified Chinese, English
- Battery capacity: 3200mAh Li-ion Battery, >10000 times(within 8 hours)
- Display: TFT color 3.5 inch display screen
- Interface: USB/RS-232
- Software: NO
- Storage data: basic mode 1000
- Operating temperature range: 0~40℃（32~104°F）
- Storage temperature range: -20~50℃（-4~122°F）
- Humidity: <85% relative humidity, no condensation
- Standard accessories: main unit, Power Adapter, USB cable, User Manual, Calibration Plat
- Optional accessories: micro printer
- If you need Optional Accessories, Please contact us.
