Application:

It is used for cloth inspection machines, cloth rolling machines, setting machines and cable machinery that need to measure the length. It is mainly used for automatic length measurement, circle counting and control. Since the sensor adopts a reversible photoelectric sensor, it overcomes the disadvantages of low life and low precision caused by mechanical wear or slippage of the mechanical measuring device. Strong ability, simple and intuitive operation display. This product is designed with a high-performance forward and reverse direction discrimination circuit, and cooperates with the photoelectric encoder to realize length measurement in two directions, that is, it can not only superimpose the meter, but also reversibly subtract the meter!

Specification:

1. Length measurement and length control range: 00000.0-99999.9m, 0000.00-9999.99m, 000000-999999m Display unit millimeters, centimeters, decimeters, meters, you can switch the yardage display with one key!
2. Reversible two-way meter
3. Pulse equivalent: adjustable from 0.00001 to 99.9999
4. Dimensions (W×H×D): 72×72×85mm Hole size (W×H): 68×68mm Circumference of meter wheel 200mm
