📋Product List
AMD Ryzen Threadripper PRO 5975WX*1
⚙️Product Specifications
AMD Ryzen Threadripper PRO 5975WX：
Specification Details Model AMD Ryzen Threadripper PRO 5975WX Architecture Zen 3 Cores / Threads 32 Cores / 64 Threads Base Clock 3.6 GHz Max Boost Clock Up to 4.5 GHz Socket sWRX8 Chipset Compatible WRX80 L2 Cache 16MB (512KB per core) L3 Cache 128MB TDP 280W Manufacturing Node TSMC 7nm FinFET Memory Support 8-Channel DDR4 ECC RDIMM/LRDIMM Max Memory Capacity Up to 2TB (with compatible WRX80 motherboard) PCIe Lanes 128 lanes of PCIe 4.0 Use Case Professional Workstation, Rendering, Simulation, AI Gigabyte MC62-G40 ：
Form Factor：CEB；305W × 267D mm
- CPU：AMD Ryzen™ Threadripper™ PRO 5000/3000 WX - Series Processors；Up to 64 cores, 128 threads；TDP up to 280W
- Socket：1 × sWRX8
- Chipset：AMD WRX80
- Memory：8 × DIMM slots；DDR4 memory supported only；8 - channel memory architecture；ECC UDIMM supported；Total capacity up to 2TB (256GB LRDIMM)；Memory speed: 3200/2933/2666/2400/2133 MT/s
- LAN：2 × 10Gb/s LAN ports (Intel® X550 - AT2)；1 × 1Gb/s LAN port (Intel® I210 - AT)；Supports NCSI function on Intel® I210 - AT；1 × 10/100/1000 Mbps Management LAN
- Video：Integrated in Aspeed® AST2600；2D Video Graphic Adapter with PCIe bus interface；1920×1200@60Hz 32bpp
- Audio：Realtek® ALC4080 HD Audio Codec；Supports 7.1 channel configuration；3 × Audio Jacks (Audio in/Audio out/Mic)
- Storage Interface：CPU: 1 × SlimSAS connector (PCIe Gen4 ×4 or SATA)；FCH: 2 × SlimSAS connectors (PCIe Gen4 ×4 or SATA), 4 × SATA 6Gb/s ports
- Note：When installing memory modules, make sure to begin with the first socket of each channel, such as DIMM_P0_A0, DIMM_P0_B0, DIMM_P0_C0, DIMM_P0_D0.
- Internal I/O：1 × 24 - pin ATX main power connector；2 × 8 - pin ATX 12V power connectors；1 × CPU fan header；1 × FCH fan header；8 × System fan headers；2 × USB 3.2 Gen1 x2 headers；2 × M.2 slots for storage；1 × M.2 slot for Wi - Fi；3 × SlimSAS connectors；4 × SATA connectors；1 × Front panel header；1 × Backplane board header；1 × COM header；1 × PMBus header；1 × IPMB header；1 × TPM header
- Rear I/O：1 × USB 3.2 Gen2x1 (Type - C)(FCH)；4 × USB 3.2 Gen2x1 (Type - A)(CPU)；1 × USB 3.2 Gen2x1 (Type - A)(FCH)；1 × VGA；2 × RJ45 (10Gb/s)；1 × RJ45 (1Gb/s)；1 × MLAN；3 × Audio jacks；1 × ID button with LED
- TPM：1 × TPM header with SPI interface；Optional TPM2.0 kit: CTM010
- OS Compatibility：Red Hat Enterprise Linux 8.2 (x64)；Red Hat Enterprise Linux 8.3 (x64)；Ubuntu 20.04 LTS (x64)；Windows 10 (x64)；Windows 11 (x64)
- Board Management：ASPEED® AST2600
- PSU Connectors：1 × 24 - pin ATX main power connector；2 × 8 - pin ATX 12V power connectors
- Operating Properties：Operating temperature: 10°C to 40°C；Operating humidity: 8 - 80% (non - condensing)；Non - operating temperature: -40°C to 60°C；Non - operating humidity: 20% - 95% (non - condensing)
