Mini Fiber Optical Laser Source Light Source SM 1310/1550nm MM 850/1300nm Cable Tester


Product Description
Optical Power Meter
Introduction
TM103N Mini Designed Optical
Power Meter is a selfdeveloped test instrument by T&M Tools, which is widely used for installation, operation and maintenance of fiberoptic network. And
it can test six calibrated
wavelength optical power within the range of 800~1700nm.

Features

1）Auto-off function  2）Backlight LCD display  3）User self-calibration function  4）SC+ST+FC connectors included  5）AAA batteries which is more convenient to carry  6）High measurement accuracy and display resolution  7）Quick response and measurement: It can display fast-tracking and real-time  8）measurement of optical power when output power changes  9）Wide measurement range: it can provide 80dB of optical power measurement
 range
10）Provide absolute optical power measurement and relative power measurement.  11）Real-time monitoring and displaying the battery level,  12）Warning notice is available when the battery is low.  13）Six calibrated wavelength: 850nm、1300nm、1310nm、1490nm 1550nm and 1625nm(other wavelength can be provided according to customer’s request)
Product Parameter
Measurement range dBm
-70～+10 dBm
-50～+26 dBm
Wavelength range（nm）
800～1650
Calibrated wavelength
850nm、1300nm、1310nm、1490nm、1550nm、1625nm
（other wavelength will be on request）
Detector
InGaAs
Accuracy
<±3% （-10dBm、22℃）
Resolution
Linearity：0.1%，Non-linearity：0.01dBm
Working temperature
-10℃～+50℃
Storage temperature
-20℃～+70℃
Relative humidity
90%（＋30℃）
connector
Movable FC/PC SC/PC，( ST as Optional)
Power supply
3pcs AAA batteries
DC power supply
Optional accessory which require special order
Support wide range power input work (AC 90-240)
Working hours
>120 hours（without backlight）
Weight(g)
128g
Dimension(mm)
64mm*32mm*15mm
Optical Light Source
Introduction
Optical laser light source is a self-developed instrument, Which features advanced control technology , high output, ultra low-power operation. It can work at 1625nm, 1550nm, 1490nm, 1310nm, 1300nm, 850nm，single wavelength, dual-wavelength or tri -wavelength. It can export a variety of modulation frequency (CW, 270HZ, 1KHZ, 2KHZ). It is widely used in optical communication, optical measurement, optical fiber sensing, and so on.

Features

1）Good stability in output power 2）Optional auto-shutdown                    3）Large LCD display and backlight  4）Battery power display

Applications

1）Maintenance Telecom 2）Maintenance CATV 3）Test Lab of Fiber Optic 4）Optical fiber sensors
Type
SR512
Emitter Type
FP-LD
Wavelength（nm）
850、1300、1310、1490、1550、1625（1-3 wave）
Optical Connector
FC（SC/ST can be optional）
Output Power(dBm)
≥ 3m w @ 650nm; ≥ -7dBm @ 850/1300nm
≥ -7/0dBm @ 1310/1490/1550/1625nm
Output Stability(dB)
±0.04@20℃@15min
Modulation Frequencies
CW,2Hz@650nm;CW,270Hz,1KHz,2KHz@others
Fiber Type
SM、MM
Power Supply
AAA 1.5V(3pcs batteries)
working time(h)
40hours
Operating Temperature(℃)
-10～+50
Storage Temperature(℃)
-20～+70
Dimension(mm)
125*65*29mm
Weight(g)
160
SR512-SM
SM-1310/1550nm Fixed FC or SC
SR512-MM
MM-850/1300nm Fixed FC or SC
SR512-SM-R
SM-1310/1550nm Replaceable FC/SC/ST
SR512-MM-R
MM-850/1300nm Replaceable FC/SC/ST
SR512-T
1310/1490/1550nm (SC/APC)
