Colorimeter Color Meter Built-in white Plate Parameters No Calibration Required
Colorimeter can easily achieve accurate color transmission, also can be used as a measuring equipment for precise color matching system. It’s widely used in traffic signs, plastics, electronics, painting, ink, textile and garment, printing and dyeing, printing paper and so on. With UV included, it can test fluorescent sample.
Feratures:
1. High performance and low price.
2. Repeatability: ΔE ≤ 0.03.
3. Double locating: Illuminating locating and precise cross locating.
4. Equipped with rechargeable Li-ion battery, no need to purchase battery repeatedly.
5. 4mm measuring aperture, portable structure, suitable for more measuring occasions.
6. White appearance, color box packaging, easy to transport.
7. Built-in white plate parameters, no need to do calibration.
8. Directly use after power on, no need to connect with computer.
Specification:
|
Illuminating/Viewing Geometry |
8°/d |
|
Standard |
CIE No.15, GB/T 3978 |
|
Sensor |
Silicon photodiode |
|
Measuring Aperture |
4mm |
|
Color Space |
CIE LAB |
|
Observer |
CIE 10° |
|
llluminant |
D65 |
|
Display Data |
Colorimetric Value, Color Difference Value Storage |
|
Temperature |
Graph, PASS/FAIL Result, Color Offset |
|
Measuring Time |
1.5s |
|
Repeatability |
ΔE* ab ≤0. 03（Average of 30 measurements of standard white plate） |
|
Dimension |
205*67*80mm |
|
Errors between each instrument |
ΔE*ab 0.4 |
|
Weight |
400g |
|
Battery |
Rechargeable lithium-ion battery 3. 7V@ 3200mAh |
|
Lamp Life |
5 years, more than 1.6 million measurements |
|
Screen |
TFT 2.8 inch(16: 9) |
|
lnterface |
USB |
|
Storage |
100 Standards, 10000 Samples |
|
Operating Temperature |
0-40°C(32-104°F) |
|
Storage temperature |
-20-50°C(-4-122°F) |
|
Optional accessory |
Miniature thermal printer, Powder test box |
