memory

Supports a maximum of 24 DDR4 DIMMs, a maximum rate of 2933MT/s, RDIMMs or LRDIMMs, and a maximum capacity of 3.0TB

Support for 12 Intel ® Outtum ™ Data Center Grade persistent memory (DCPMM)

Memory controller

The standard onboard array controller supports SATA RAID 0, 1, 10, and 5

Optional HBA card based on the dedicated slot of the array card, supporting SATA or SAS RAID 0/1/10

Optional Array cards based on the dedicated slots of the array card. RAID0, 1, 10, 5/6/6/50/60/1E is supported

Optional Hbas and array cards based on standard PCIe slots

FBWC

Supports a maximum of 4GB DDR4-2133 MHZ cache

storage

The highest support is 12LFF in the front, 4LFF in the interior, 4LFF plus 4SFF in the rear [7];

Maximum support front 25SFF, internal extension 8SFF, rear extension 3LFF plus 4SFF[8] Support SAS/SATA HDD/SSD hard disks;

Support for front/built-in NVMe hard drives, up to 32 front NVMe hard drives [9]

Supports 480GB SATA M.2 Optional

network

One onboard 1 Gbit/s management network port

You can expand 4 x 1GE electrical ports or 2 x 10GE electrical or optical ports through the mLOM

Optional Network adapters based on standard PCIe slots

Expansion slot

Up to 10 available PCIe 3.0 slots (1 slot dedicated to array card and 1 slot dedicated to network card)

interface

Optional front VGA, standard rear VGA and serial port, 5 USB 3.0 (1 front, 2 rear, 2 built-in), optional 1 USB 2.0 and 2 MicroSD

GPU support

Supports three dual-width Gpus or eight single-width Gpus

Optical drive

Support external optical drive, 8SFF models support built-in optical drive

management

HDM has no agent management tool (with independent management port) and H3C FIST management software

security

Supports chassis intrusion detection, TCM/TPM security module, and PCIe protection module, providing firewall, IPS, antivirus, and QoS defense functions

Power supply and heat dissipation

The optional platinum level is 550W / 800W / 850W / 1200W / 1600W 1+1 redundancy power supply. The optional Titanium level 1+1 redundancy power supply is optional

800W minus 48V / 336V DC power module in 1+1 redundancy

Supports hot-swappable redundant fans

certification

Support CCC, CECP, SEPA, CE, CB and other certifications

Operating temperature

5 ° C to 50 ° C (The operating temperature is affected by different configurations. For details, see the detailed product technical documentation.)

Shape/chassis depth

87.5mm(H)* 445.5mm(W)* 748mm(D) (without safety panel)

87.5mm(H)* 445.5mm(W)* 769mm(D) (including safety panel)
