Product Description

Advantages:


【Software Update MPPT Design 】100% MPPT 60A solar charge controller Intelligent, Max efficiency ≥98.1%, PV utilization ≥99%. Built-in DSP controller with high performance Automatic battery voltage detection 12V/24V/36V/48V, Make sure batteries' voltage more than 12V to boost controller and make sure battery has enough power to Self-detection when connected to the controller.

【Multiple Battery Adaptation】 Fit for USER(can be set Lithium, Lifepo4, Li(NiCoMn)O2)/Vented/Flooded/Sealed/Gel/NiCd battery. User programmable for absorption voltage/Floating voltage/Low voltage disconnect./Load Timer. Real-time energy recording. Two connectors for each pos and negs on solar and batteries connectors. copper wires:9AWG.

【Full System Protection】Backlight LCD Dispaly PV voltage/output power/Battery voltage/charging current/working mode/Temperature. ☀ TROUBLESHOOTING function and LCD display and can help users not only check the whole system operating data and statuses but also quickly identify system faults and modify parameters.

【Fan Heat Dissipation】Intelligence Fan-on temperature >45℃ and off < 40℃,Porous heat dissipation.and fan use BEARING technologies increase life UP TO 5000hrs in normal use. Suitable for RVs, Commercial Vehicles, Boats, Yachts, and Solar system.

【Notiction】If you use sealed lead acid, vented gel battery, and etc, you donn't need to set any parameters, the controller can adjuste automaticly and work normally; but if you use lithium batteries, you need to properly adjuste parameters according to the actual voltage of the battery, becauese the voltage of lithium batteries is unstable, such as acid battery 12V is 12V, lithium battery 12V may be 11.1V or 14.8V.


Feature:


* Charging 3-stage: constant current(MPPT), constant voltage(Absorption Voltage), floating charge

Selectable battery type Vented / Sealed / Gel / NiCd / Lithium battery (default is Sealed) (defined voltage for other battery by user)

* Soft start time ≤1S, Dynamic response and recovery time 100us

* Max efficiency ≥98.1%, PV utilization ≥99%

* In order to reduce the cost of electricity caused by high current, PV and battery each have two terminals

* MULTIPLE ELECTRONIC PROTECTIONS

   Short-circuting

   Reverse-current

   Overcharging

   Overload

   Over-discharging

   Reverse polarity protection

Notes: The output terminal is for lamp only( 12V system less 60W, 24V/36V/48V system less 100W ),and it will be burnt if connecting to other loads. The output for battery is no polarity reverse protection.


Remarks:


1. The maximum PV input voltage (Voc): DC160V (The controller can not work with this long duration voltage, which will interrupt the controller. Refer to the input voltage of PV).

2. The output port is only for lamps (12V system less 60W, 24V/36V/48V system less 100W) and will be burned if connected to other loads. The battery output is not reverse polarity protection.

3. Always connect the battery first!!! Make sure the battery voltage is sufficient for the controller to recognize the correct system voltage. The order of dismantling contradicts the order of wiring.

4. Do not connect any inverter/wind/generator or charger to the controller, please connect the inverter to the battery side.

5. Ensures the solar input voltage exceeds 3V or more than the battery voltage and the total input power exceeds the max. , the charging current is almost zero when the controller has trickle charge.


You can Put two pieces 60A in parallel ,So total is MPPT 120A.


Specifications:


Model: HHJ-60A

Screen Type: LCD

Color: White / Blue

Voltage Specifications: 12/24/36/48V Auto

Cover Material: Aluminium Alloy

Charge Mode: MPPT Automatic Maximum Impetus Point Tracking

Charge Way: MPPT, Constant Voltage, Floating Charge

Dynamic Response Recovery Time: 100us

Overall Efficiency: ≥98.1%

Photovoltaic Module Utilization: ≥99%

Maximum Limit Input Voltage: DC190V

Item Weight: 1130g / 39.86ounces

Package Weight: 1330g / 46.91ounces

Item Size: 215 * 115 * 50mm / 8.46 * 4.53 * 1.97in

Package Size: 260 * 200 * 70mm / 10.24 * 7.87 * 2.76in


Package Included:


1 x Solar Controller

1 x Instruction Book In English

1 x Fixed Parts Package
