6' X 17" CARLTON MODEL #4A RADIAL ARM DRILL PRESS: STOCK #22087

Machine Details:

Type

Brand

Model

Drills, Radial

CARLTON

06 X 17 4A
 

Specifications:

SERIAL ........................... 4A 5720
MODEL ............................ 4A
AREA OF BASE ..................... 77" X 48"
SPINDLE SPEEDS ................... (36) 12 TO 1200 RPM
SPINDLE FEEDS .................... (18) .004 TO .125 IPR
TAPS.............................. 8, 11-1/2, 14, 18 TPI
DIAMETER OF SPINDLE .............. 3-3/16"
TAPER IN SPINDLE ................. #5 MT
SPINDLE TRAVEL ................... 18"
DISTANCE SPINDLE TO COLUMN ....... 13-1/2" TO 72" MAXIMUM
DISTANCE SPINDLE TO BASE ......... 14-1/2" TO 72" MAXIMUM
TRAVEL OF HEAD ON ARM ............ 58-3/4"
TRAVEL OF ARM ON COLUMN .......... 37-1/2"
POWER HEAD CLAMPING .............. YES
POWER HEAD TRAVERSE .............. YES
POWER ARM ELEVATION .............. YES
POWER ARM CLAMPING ............... YES
COOLANT .......................... YES
MAIN MOTOR ....................... 15 HORSEPOWER

Payment

Payment will be processed before shipping and is non-refundable.

Terms & Conditions

Machines are bought as-is and cannot be refunded. Buyer is responsible for inspection and purchase before paying.
