SW3518P
Product Features:
This product adopts SW3518P, which supports most of the cell phone models on the market!
This product is compact (50*17*12mm), more suitable for user DIY!
Such as with a 12-volt power adapter can be daily cell phone fast-charging, at the same time can be powered by batteries, solar panels, DC wind generators and so on!
One machine for two purposes! Outdoor/vehicle/long-term power outages and other occasions a good helper! This is ordinary cell phone charger and charging treasure can not do!
Keep one at home, one more way to charge more assured!
This product adopts SW3518P, which supports most of the cell phone models on the market!
This product is compact (50*17*12mm), more suitable for user DIY!
Such as with a 12-volt power adapter can be daily cell phone fast-charging, at the same time can be powered by batteries, solar panels, DC wind generators and so on!
One machine for two purposes! Outdoor/vehicle/long-term power outages and other occasions a good helper! This is ordinary cell phone charger and charging treasure can not do!
Keep one at home, one more way to charge more assured!
Product Features:
Support one, strong compatibility USB PD3.0 (PPS), support Qualcomm QC4+/QC4.0/QC3.0
Support two, high efficiency, full power using external MOS tubes, dual-wire parallel winding ferrosilicon aluminum magnetic ring, high efficiency, lower heat under the same charging power!!!! Double parallel low resistance electrolytic capacitors + 6 1206 ceramic capacitors! Only for higher performance! Actual test chart: perfect realization of Huawei super fast charging 5V4.5A (SCP)
Support three, additional configuration 1, flexible power supply mode full protocol fast charging module standard red and black power supply line, such as optional shell is the default power supply interface for the 5.5mm female socket and standard 5.5 male line! 2, wide power supply voltage: 6 to 35V! 3, high-performance input anti-reverse connection dedicated to do anti-reverse connection of a MOS tube, although the cost is high, but the effect is far more than the diode, do not get hot! (Heat generation is close to zero) 4, with fast charging status indicator blue light for the output indication, red light for fast charging status indication! 5, dual-channel independent current limiting 6, ultra-thin design, optional shell! 50*17*12mm
Attention
The shell is modified by hand! The details of the pursuit of perfection of the user to shoot with caution! The default power supply with shell is 5.5mm plug!
For low-voltage high-current fast charging, please use the original cable, such as want to measure the charging voltage and current, must use a low internal resistance type USB meter! Otherwise it will affect the charging current!
3, TYPE_C port is used for output charging; with C-TO-C/TYPE_C male-to-male dual-ended data cable to charge your cell phone or laptop!
4, OPPO and OnePlus phone charging have to use the USB port! QC4+/QC4.0/PD3.0 and other protocols have to use TYPE_C port!
5, the supply voltage is higher than 21 volts when the C port PD protocol supports up to 20V3A output, the module is small in size, used for laptop with PD charging, please good ventilation and heat dissipation!
6, when the USB port and TYPE_C port at the same time plugged into a cell phone, the dual-port are 5V output!
Fifth, multi-brand cell phone charging test USB port:
1, charging Huawei Mate20 (power 56%): open SCP fast charging mode voltage 4.89V, current 4.59A
2, charge Huawei P20 Pro (power 12%): open SCP fast charging mode voltage 5.03V, current 4.25A
3, charging glory V20 (power 43%): open SCP fast charging mode voltage 5.13V, current 4.5A4, charging millet 8 (power 18%): open QC3.0 fast charging mode voltage 6.44V, current 2.79A5, charging OPPO R17 (power 43%): open VOOC flash charging mode voltage 4.8V, current 3.8A6, charging iPhone XS (power 5%): open APPLE2.4A mode voltage 5.22V, current 2.37A 7, charging a plus 6T (power 15%): open DASH flash charging mode voltage 4.7V, current 3.8A Type_C port: 1, charging the iPhone XR (power 7%): open PD voltage 9.17V, current 1.91A2, charging the iPhone X (power 7%): open PD voltage 9.17V, current 1.91A2, charging the iPhone X (power 7%): open PD voltage 9.17V, current 1.6A3, charging Huawei Mate20Pro (power 55%): open PD voltage 9.20V, current 1.58A4, charging Huawei P20 Pro (power 10%): open PD voltage 9.17V, current 1.69A5, charging honor V20 (power 40%): open PD voltage 9.05V Charge Xiaomi 8 (power 6%) : Turn on fast charging voltage 6.1V, current 2.63A
Support one, strong compatibility USB PD3.0 (PPS), support Qualcomm QC4+/QC4.0/QC3.0
Support two, high efficiency, full power using external MOS tubes, dual-wire parallel winding ferrosilicon aluminum magnetic ring, high efficiency, lower heat under the same charging power!!!! Double parallel low resistance electrolytic capacitors + 6 1206 ceramic capacitors! Only for higher performance! Actual test chart: perfect realization of Huawei super fast charging 5V4.5A (SCP)
Support three, additional configuration 1, flexible power supply mode full protocol fast charging module standard red and black power supply line, such as optional shell is the default power supply interface for the 5.5mm female socket and standard 5.5 male line! 2, wide power supply voltage: 6 to 35V! 3, high-performance input anti-reverse connection dedicated to do anti-reverse connection of a MOS tube, although the cost is high, but the effect is far more than the diode, do not get hot! (Heat generation is close to zero) 4, with fast charging status indicator blue light for the output indication, red light for fast charging status indication! 5, dual-channel independent current limiting 6, ultra-thin design, optional shell! 50*17*12mm
Attention
The shell is modified by hand! The details of the pursuit of perfection of the user to shoot with caution! The default power supply with shell is 5.5mm plug!
For low-voltage high-current fast charging, please use the original cable, such as want to measure the charging voltage and current, must use a low internal resistance type USB meter! Otherwise it will affect the charging current!
3, TYPE_C port is used for output charging; with C-TO-C/TYPE_C male-to-male dual-ended data cable to charge your cell phone or laptop!
4, OPPO and OnePlus phone charging have to use the USB port! QC4+/QC4.0/PD3.0 and other protocols have to use TYPE_C port!
5, the supply voltage is higher than 21 volts when the C port PD protocol supports up to 20V3A output, the module is small in size, used for laptop with PD charging, please good ventilation and heat dissipation!
6, when the USB port and TYPE_C port at the same time plugged into a cell phone, the dual-port are 5V output!
Fifth, multi-brand cell phone charging test USB port:
1, charging Huawei Mate20 (power 56%): open SCP fast charging mode voltage 4.89V, current 4.59A
2, charge Huawei P20 Pro (power 12%): open SCP fast charging mode voltage 5.03V, current 4.25A
3, charging glory V20 (power 43%): open SCP fast charging mode voltage 5.13V, current 4.5A4, charging millet 8 (power 18%): open QC3.0 fast charging mode voltage 6.44V, current 2.79A5, charging OPPO R17 (power 43%): open VOOC flash charging mode voltage 4.8V, current 3.8A6, charging iPhone XS (power 5%): open APPLE2.4A mode voltage 5.22V, current 2.37A 7, charging a plus 6T (power 15%): open DASH flash charging mode voltage 4.7V, current 3.8A Type_C port: 1, charging the iPhone XR (power 7%): open PD voltage 9.17V, current 1.91A2, charging the iPhone X (power 7%): open PD voltage 9.17V, current 1.91A2, charging the iPhone X (power 7%): open PD voltage 9.17V, current 1.6A3, charging Huawei Mate20Pro (power 55%): open PD voltage 9.20V, current 1.58A4, charging Huawei P20 Pro (power 10%): open PD voltage 9.17V, current 1.69A5, charging honor V20 (power 40%): open PD voltage 9.05V Charge Xiaomi 8 (power 6%) : Turn on fast charging voltage 6.1V, current 2.63A
Product list;
1X module
1X module
|
SW3518
|
Product Features:
1. Compact size, fast charging output, dual-port charging chip
2. Support A + C port any port fast charging output, USB TYPE-A and TYPE-C dual port output
3. Support PPS/PD/QC/AFC/FCP/SCP/PE/SFCP/VOOC and other fast charging protocols.
4. Support 6~30V voltage regulation, 24V power supply is recommended.
5. Support USB Type-A and Type-C dual port output
1. Compact size, fast charging output, dual-port charging chip
2. Support A + C port any port fast charging output, USB TYPE-A and TYPE-C dual port output
3. Support PPS/PD/QC/AFC/FCP/SCP/PE/SFCP/VOOC and other fast charging protocols.
4. Support 6~30V voltage regulation, 24V power supply is recommended.
5. Support USB Type-A and Type-C dual port output
Product Description:
SW3518S is a highly integrated dual-port charging chip with multiple fast charging protocols, supporting any port A+C fast charging output and dual-port independent current limiting. It integrates a 5A high efficiency synchronous buck converter and supports multiple fast charging protocols such as PPS/PD/QC/AFC/FCP/SCP/PE/SFCP/VOOC.
SW3518S is a highly integrated dual-port charging chip with multiple fast charging protocols, supporting any port A+C fast charging output and dual-port independent current limiting. It integrates a 5A high efficiency synchronous buck converter and supports multiple fast charging protocols such as PPS/PD/QC/AFC/FCP/SCP/PE/SFCP/VOOC.
Product Parameters:
Product name:SW3518 all protocol cell phone fast charging module
Voltage range:6~30V
Power supply: 5.5x2.1mm power socket, power supply or welding wire into the power supply
Product size: 65*20*12mm
Output port: USB Type-A and Type-C
AFC fast charging protocol, output support 5V/9V/12V
FCP fast charging protocol, output support 5V/9V/12V
SCP快充协议,输出支持5V@4.5A, 4.5V@5A
Product name:SW3518 all protocol cell phone fast charging module
Voltage range:6~30V
Power supply: 5.5x2.1mm power socket, power supply or welding wire into the power supply
Product size: 65*20*12mm
Output port: USB Type-A and Type-C
AFC fast charging protocol, output support 5V/9V/12V
FCP fast charging protocol, output support 5V/9V/12V
SCP快充协议,输出支持5V@4.5A, 4.5V@5A
Instructions for use:
It can be powered by 5.5X2.1MM power socket, or solder your own wire to access the power supply.
The power supply voltage range is 6~30V.
The red indicator light will be on after plugging in the power supply, if you plug in the device without fast charging, there will be 5V power output from USBA port or C port.
If inserted into devices with fast charging, such as cell phones, power decoys, etc., the blue indicator light is on, indicating that it enters the fast charging mode. The output voltage and current is adjusted by the device such as cell phone or power decoy.
SW3518S integrates QC fast charging protocol, supports QC4+/QC4/QC3.0/QC2.0,
Support CLASS A/CLASS B.
QC2.0 output supports 5V/9V/12V/20V.
QC3.0 output supports 3.6V~20V, 200MV/STEP.
SW3518S integrated AFC fast charging protocol, output support 5V/9V/12V.
SW3518S integrated FCP fast charging protocol, output support 5V/9V/12V.
SW3518S integrated SCP fast charging protocol, 输出支持5V@4.5A, 4.5V@5A
SW3518S Integrated PE2.0 and PE1.1 fast charging protocol, PE2.0 output support
5V~20V, 50OMV/STEP. PE1.1 output supports 5V/7V/9V/12V.
SW3518S integrates SFCP fast charging protocol, the output supports 5V/9V/12V.
SW3518S integrated VOOC fast charging protocol, 输出支持5V@4.25A
SW3518S contains a USB intelligent adaptive function module, which not only supports BC1.2 function, as well as China's cell phone charger standard, but also well compatible with Apple and Samsung's high-current output recognition Type-C interface in PD3.0 mode stable output 20V 4A 80W
It can be powered by 5.5X2.1MM power socket, or solder your own wire to access the power supply.
The power supply voltage range is 6~30V.
The red indicator light will be on after plugging in the power supply, if you plug in the device without fast charging, there will be 5V power output from USBA port or C port.
If inserted into devices with fast charging, such as cell phones, power decoys, etc., the blue indicator light is on, indicating that it enters the fast charging mode. The output voltage and current is adjusted by the device such as cell phone or power decoy.
SW3518S integrates QC fast charging protocol, supports QC4+/QC4/QC3.0/QC2.0,
Support CLASS A/CLASS B.
QC2.0 output supports 5V/9V/12V/20V.
QC3.0 output supports 3.6V~20V, 200MV/STEP.
SW3518S integrated AFC fast charging protocol, output support 5V/9V/12V.
SW3518S integrated FCP fast charging protocol, output support 5V/9V/12V.
SW3518S integrated SCP fast charging protocol, 输出支持5V@4.5A, 4.5V@5A
SW3518S Integrated PE2.0 and PE1.1 fast charging protocol, PE2.0 output support
5V~20V, 50OMV/STEP. PE1.1 output supports 5V/7V/9V/12V.
SW3518S integrates SFCP fast charging protocol, the output supports 5V/9V/12V.
SW3518S integrated VOOC fast charging protocol, 输出支持5V@4.25A
SW3518S contains a USB intelligent adaptive function module, which not only supports BC1.2 function, as well as China's cell phone charger standard, but also well compatible with Apple and Samsung's high-current output recognition Type-C interface in PD3.0 mode stable output 20V 4A 80W
Product list:
