VXF4CM14BPRO ¼" NPT Manifold Air Valve Red

This manifold will inflate and deflate the air springs using two ¼" NPT Intake and two ¼" NPT Exhaust ports. The ports connecting the air line to the air spring are ¼" NPT while the ports connecting the air lines to the air gauges are ¼" NPT. Includes a 7-Switch Controller with weather-proof plug-n-play harness that not only controls 8 valves individually, but also improves the appearance and guarantees proper operation on every set-up. The robust internal solenoid valve structure maximizes flow rates and guarantees operation up to 230 PSI for millions of cycles. In addition, the manifold can be connected to a switch panel or remote control using the included wire harness with color-coded wires which provides a seamless installation and reliable operation with your accessories.

• ¼" NPT Suspension Manifold Air Valve (Red)
• Power Source: 12V
• Max Air Pressure: 230 PSI
• Two ¼" NPT Female Inlet ports
• Two ¼" NPT Female Exhaust ports
• Four ¼" NPT Female Air Spring Ports
• Four ¼" NPT Female Air Gauge Ports
• Fully Sealed Enclosure
• Dust and Water Protection (IP65 Rated)
• 2-way valves (normally closed)
• 7-switch Controller with weather-proof plug-n-play 8 FT fused harness for fast and accurate wire connections
• Included with this kit:
  • Wire Harness to control the valves with external switches or remote
  • ¼" NPT Male Plug x 1 (to close one intake port if running only one air line from the tank)
  • ¼" NPT Male Plug x 4 (to close the Air Gauge Ports if not planning to use Air Gauges)
  • Mounting Hardware
• Dimensions: 6-¼" W x 2-¾" H x 2-¾" D

Note: This manifold will operate four air springs (Inflate/Deflate)
